Ford Escape I facelift 2 (2007-2012) rear reverse defrost lamp relay relay Wiring diagram
This page shows the only wiring diagram for the component.rear reverse defrost lamp relay relay, which is found in the car Ford Escape I facelift 2 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear reverse defrost lamp relay relay (1 of 1)
AC OUTLET CONNECTOR
AC-A
AC-B
BATTERY JUNCTION BOX (BJB) (LEFT REAR OF ENGINE COMPT)
BLK/GRY WIRE
BLU WIRE
BLU/BRN WIRE
DC/AC INVERTER MODULE (UNDER FRONT OF CENTER CONSOLE)
EVAP CANISTER VENT CONTROL SOLENOID
FROM FUSE 3 (DIAGRAM 1 OF 5)
FROM FUSE 35 (DIAGRAM 5 OF 5)
FROM FUSE 5 (DIAGRAM 2 OF 5)
FUSE 15
FUSE 24
FUSE 25
FUSE 26
FUSE 29
FUSE 35
FUSE 5
GRN WIRE
GRN/RED WIRE
GRY WIRE
INERTIA FUEL SHUTOFF (IFS) SWITCH
LED
LED GND
LEFT FRONT PARK/ TURN LIGHT
ORG/ WIRE
ORG/GRN WIRE
ORG/WHT WIRE
PCM POWER DIODE
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
REAR REVERSE DEFROST LAMP RELAY RELAY
RED WIRE
TO FUSE 27 (DIAGRAM 3 OF 5)
TO FUSE 29 (DIAGRAM 5 OF 5)
TO INJECTOR RELAY (DIAGRAM 5 OF 5)
TO PCM RELAY (DIAGRAM 2 OF 5)
TO SPLICE
TRACTION BATTERY CONTROL MODULE
TRANSAXLE CONTROL MODULE
VBATT
VIO WIRE
VPWR
WHT WIRE
YEL WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component -> Power distribution circuit, hybrid (2 of 5) -> REAR REVERSE DEFROST LAMP RELAY RELAY
