Ford Escape I facelift 2 (2007-2012) in car temp sens pass temp act fdbk pass temp dr ccw pass temp dr cw Wiring diagram

24 25 26 FR BLWR RELAY MS CAN+ MS CAN- AIR INLET CCW OSA AIR INLET CW REC BATTERY JUNCTION BLK/BLU WIRE BLK/GRN WIRE BLOWER MOTOR RELAY BLOWER MOTOR SPEED CONTROL BLU/BRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BLWR CTRL (VBC) BOX (BJB) (LEFT FRONT OF ENGINE COMPT) BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DATC HVAC MODULE DEFOGGER SYSTEM DRV HTD SEAT RLY FRONT BLOWER MOTOR (RIGHT SIDE OF DASH) FUSE 12 FUSE 15 FUSE 37 FUSE 45 LOGIC GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR ACC HOT IN RUN OR START IN CAR TEMP SENS PASS TEMP ACT FDBK PASS TEMP DR CCW PASS TEMP DR CW IN-VEHICLE TEMPERATURE SENSOR (LEFT SIDE OF DASH) MODE DR 1 CCW MODE DR 1 CW DRV TEMP DR CCW DRV TEMP DR CW GND MOT- PASS HTD SEAT RLY PASSENGER TEMPERATURE BLEND DOOR ACTUATOR (RIGHT SIDE OF DASH) POWER DISTRIBUTION SYSTEM PWM SEATS SYSTEM SMART JUNCTION BOX (SJB) (CENTER OF DASH) V IGN V BATT VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE
