Horn circuit for Ford Escape I (2000-2004)
Horn circuit
AIR BAG SLIDING CONTACT
CENTRAL BOX JUNCTION (BELOW LEFT END OF DASH)
DK BLU WIRE
ENGINE COMPT)
FUSE 23
GENERIC ELECTRONIC MODULE (GEM) (BEHIND LOWER CENTER OF DASH)
HORN RELAY
HOT AT ALL TIMES
LEFT HORN (LEFT FRONT OF
NCA WIRE
RIGHT HORN (RIGHT FRONT OF
STEERING WHEEL/ SPEED CONTROL SWITCH HORN SWITCH
W/ CRUISE CONTROL
W/O CRUISE CONTROL
YEL/GRN WIRE
