Ford Escape I (2000-2004) Body computer circuits

ANTI-THEFT SYSTEM (FORCED ENTRY CIRCUIT) ANTI-THEFT SYSTEM (FORCED ENTRY CIRCUIT) INTERIOR LIGHTS SYSTEM BLK WIRE BLK/LT GRN WIRE BLK/PNK WIRE BLK/WHT WIRE CENTRAL JUNCTION BOX (BELOW LEFT END OF DASH) DK BLU WIRE DK BLU/LT GRN WIRE DK GRN/VIO WIRE DOOR UNLOCK INPUT DOOR UNLOCK OUT GROUND DOOR LOCK OUT BATTERY SAVER RELAY CTRL DOOR UNLOCK OUTPUT POWER-BATTERY EXTERIOR LIGHTS SYSTEM INSTRUMENT CLUSTER SYSTEM COMPUTER DATA LINES SYSTEM FUSE 16 FUSE 26 FUSE 27 FUSE 8 GENERIC ELECTRONIC MODULE (GEM) (BEHIND LOWER CENTER OF DASH) HOT AT ALL TIMES HOT IN ACC OR RUN HOT IN RUN OR START INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM KEY IN IGNITION SW HEADLAMP RELAY CNTL LT BLU/BLK WIRE LT BLU/RED WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE LT GRN/YEL WIRE ORG/ WIRE ORG/BLK WIRE ORG/LT GRN WIRE PNK WIRE PNK/BLK WIRE PNK/LT BLU WIRE PNK/ORG WIRE PNK/WHT WIRE RED WIRE RED/ORG WIRE RED/WHT WIRE RED/YEL WIRE VIO/LT GRN WIRE VIO/ORG WIRE WARNING SYSTEM HEADLIGHTS SYSTEM WHT WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE
