Ford Escape I (2000-2004) passenger side window adjust switch Wiring diagram
This page shows the only wiring diagram for the component.passenger side window adjust switch, which is found in the car Ford Escape I (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger side window adjust switch (1 of 1)
ACCESSORY DELAY RELAY
BATTERY JUNCTION BOX (BJB)
BLK WIRE
CENTRAL JUNCTION BOX (CJB)
DOWN
DOWN SWITCH
DOWN UP LEFT REAR SWITCH
DRIVER SIDE FRONT POWER WINDOW MOTOR
DRIVER'S SWITCH
FUSE 11
FUSE 20
GENERIC ELECTRONIC MODULE (GEM) (BEHIND LOWER CENTER OF DASH)
GRY WIRE
HOT AT ALL TIMES
ILLUMINATION
LEFT REAR POWER WINDOW MOTOR
LEFT REAR WINDOW ADJUST SWITCH
LOCKOUT SWITCH
LT BLU WIRE
LT BLU/RED WIRE
MASTER WINDOW/DOOR LOCK/UNLOCK SWITCH
ORG/ WIRE
PASSENGER SIDE FRONT POWER WINDOW MOTOR
PASSENGER SIDE WINDOW ADJUST SWITCH
PASSENGER'S SWITCH
RED WIRE
RED/LT BLU WIRE
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR SWITCH
RIGHT REAR WINDOW ADJUST SWITCH
TAN WIRE
TAN/BLK WIRE
UP DOWN
UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Power window circuit -> PASSENGER SIDE WINDOW ADJUST SWITCH
