Ford Escape I (2000-2004) high beam ind right turn ind Wiring diagram

ANTI- THEFT IND ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/WHT WIRE BLK/YEL WIRE BRAKE FLUID LEVEL SWITCH (ON BRAKE MASTER CYLINDER FLUID RESERVOIR) BRAKE SHIFT INTERLOCK CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FUSE 4 CHARGE IND CHECK ENGINE IND CONN A CONN B CRUISE CONTROL SYSTEM DATA LINK CONNECTOR (DLC) (LOWER LEFT SIDE OF DASH) 2 10 DAYTIME RUNNING LAMPS (DRL) MODULE (LOWER LEFT END OF DASH) DK BLU WIRE DK GRN WIRE DK GRN/LT GRN WIRE DK GRN/WHT WIRE DOOR AJAR IND ENGINE COOLANT TEMP. GAUGE EXTERIOR LIGHTS SYSTEM STARTING/CHARGING SYSTEM FOUR WHEEL DRIVE SWITCH FOUR-WHEEL DRIVE RELAY (LEFT SIDE OF CARGO COMPT,BEHIND TRIM) FUEL GAUGE FUSE 16 FUSE 18 FUSE 27 FUSE 8 GENERIC ELECTRONIC MODULE (GEM) (BEHIND LOWER CENTER OF DASH) GRN WIRE GRY/BLK WIRE HEADLIGHTS SYSTEM HIGH BEAM IND RIGHT TURN IND HOT AT ALL TIMES HOT IN ACC OR RUN HOT IN START OR RUN IGNITION SWITCH INSTRUMENT CLUSTER INTERIOR LIGHTS SYSTEM (CONN C) LEFT TURN IND AIR BAG IND LOW COOLANT IND O/D OFF IND ABS IND LOW FLUID/PARK BRAKE IND LOW FUEL IND LOW OIL IND SPEED CNTRL IND LT BLU WIRE LT BLU/BLK WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/WHT WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE PARKING BRAKE SWITCH (AT BASE OF PARK BRAKE LEVER) PNK/LT BLU WIRE POWERTRAIN CONTROL MODULE IN RECESS ON UPPER CENTER OF FIREWALL) RED WIRE RED/BLK WIRE RED/YEL WIRE RESTRAINTS CONTROL MODULE (BENEATH LOWER CENTER OF DASH, ON TRANSMISSION TUNNEL) SAFETY BELT IND SAFETY BELT SWITCH (BASE OF LEFT "B" PILLAR) SPEEDOMETER TACHOMETER TAN/ORG WIRE TRANSMISSIONS VIO/LT GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/RED WIRE YEL/BLK WIRE YEL/RED WIRE YEL/WHT WIRE
