Ford Escape I (2000-2004) blk Wiring diagrams

BATTERY BATTERY JUNCTION BOX (BJB) (LEFT FRONT CORNER OF ENGINE COMPARTMENT) FUSE 11 BLK WIRE BRN WIRE CENTRAL JUNCTION BOX (CJB) (BELOW LEFT END OF DASH) CHARGE INDICATOR FUSE FUSE 16 GENERATOR GRY WIRE HOT AT ALL TIMES HOT IN START OR RUN INSTRUMENT CLUSTER LT GRN/RED WIRE ORG/ WIRE POWERTRAIN CONTROL MODULE RED WIRE RED/YEL WIRE STARTER MOTOR WHT WIRE YEL WIRE

BATTERY BATTERY JUNCTION BOX (BJB) (LEFT FRONT CORNER OF ENGINE COMPARTMENT) FUSE 11 BLK WIRE CENTRAL JUNCTION BOX (CJB) (BELOW LEFT END OF DASH) CHARGE INDICATOR FUSE FUSE 16 GENERATOR HOT AT ALL TIMES HOT IN START OR RUN INSTRUMENT CLUSTER LT GRN/RED WIRE RED WIRE RED/YEL WIRE STARTER MOTOR WHT WIRE YEL WIRE

BLK WIRE CENTRAL JUNCTION BOX (CJB) (BELOW LEFT END OF DASH) DIFFERENTIAL LOCK SOLENOID (UNDER CENTER REAR OF VEHICLE) DK BLU WIRE DK GRN WIRE DRIVER'S SIDE FRONT SEAT ADJUST SWITCH, GENERIC ELECTRONIC MODULE FOUR WHEEL DRIVE SWITCH FOUR- WHEEL DRIVE FOUR-WHEEL DRIVE RELAY (LEFT SIDE OF CARGO COMPARTMENT, BEHIND TRIM) FUSE 26 FUSE 4 HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT CLUSTER LT BLU WIRE LT GRN WIRE MICROPROCESSOR RED WIRE WHT WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ILLUMINATION GROUND FUSED IGNITION ANTENNA AUDIO UNIT BLK WIRE BLK/LT GRN WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (BELOW LEFT END OF DASH) FUSE 12 DK GRN/ORG WIRE FUSE 27 10 GRY/LT BLU WIRE HOT AT ALL TIMES HOT AT ALL TIMES IGNITION SWITCH HOT IN RUN OR ACC LEFT FRONT SPEAKER LEFT REAR SPEAKER LT BLU WIRE LT BLU/RED WIRE LT BLU/WHT WIRE LT GRN WIRE NCA WIRE OFF ORG/ WIRE ORG/LT GRN WIRE ORG/RED WIRE RIGHT FRONT SPEAKER RIGHT REAR SPEAKER RUN WIRE TAN WIRE TAN/LT BLU WIRE TAN/YEL WIRE WHT/LT GRN WIRE YEL WIRE YEL/BLK WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ILLUMINATION GROUND FUSED IGNITION ANTENNA AUDIO UNIT BLK WIRE BLK/LT GRN WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (BELOW LEFT END OF DASH) DK GRN/ORG WIRE FUSE 12 FUSE 19 FUSE 27 GRY/BLK WIRE GRY/LT BLU WIRE HOT AT ALL TIMES HOT AT ALL TIMES IGNITION SWITCH HOT IN RUN OR ACC LEFT FRONT SPEAKER LEFT REAR SPEAKER LT BLU WIRE LT BLU/RED WIRE LT BLU/WHT WIRE LT GRN WIRE NCA WIRE OFF ORG/ WIRE ORG/LT GRN WIRE ORG/RED WIRE RED WIRE RED/YEL WIRE RIGHT FRONT SPEAKER RIGHT REAR SPEAKER RUN WIRE SUBWOOFER AMPLIFIER (ON RIGHT SIDE OF CARGO COMPT, BEHIND TRIM) TAN WIRE TAN/LT BLU WIRE TAN/YEL WIRE WHT/LT GRN WIRE YEL WIRE YEL/BLK WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ILLUMINATION GROUND FUSED IGNITION 1 2 3 4 5 6 7 8 9 10 LOW MUTE GROUND 1 2 3 4 5 6 7 8 SUBWFR LOW - SUBWFR LOW + GROUND SUBWFR LOW MUTE ANTENNA AUDIO UNIT BLK WIRE BLK/LT GRN WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (BELOW LEFT END OF DASH) DK BLU/ORG WIRE DK GRN/ORG WIRE FLOOR) FUSE 12 FUSE 19 FUSE 27 GRY/BLK WIRE GRY/LT BLU WIRE HOT AT ALL TIMES HOT AT ALL TIMES IGNITION SWITCH HOT IN RUN OR ACC LEFT FRONT SPEAKER LEFT FRONT TWEETER LEFT REAR SPEAKER LOW LOW LT BLU WIRE LT BLU/RED WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE NCA WIRE OFF ORG/ WIRE ORG/LT GRN WIRE ORG/RED WIRE PNK/LT GRN WIRE POWER RED WIRE RED/YEL WIRE RIGHT FRONT SPEAKER RIGHT FRONT TWEETER RIGHT REAR SPEAKER RUN WIRE SUBWOOFER AMPLIFIER (ON RIGHT SIDE OF CARGO COMPT, BEHIND TRIM) TAN WIRE TAN/LT BLU WIRE TAN/YEL WIRE WHT/LT GRN WIRE YEL WIRE YEL/BLK WIRE

BLK WIRE BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) BRAKE SHIFT INTERLOCK (BEHIND LEFT SIDE OF DASH, NEAR STEERING COLUMN) BRAKE SHIFT INTERLOCK DIODE (BEHIND LEFT SIDE OF DASH) BRAKE SHIFT INTERLOCK RELAY (BEHIND LEFT SIDE OF OF DASH, NEAR STEERING COLUMN) CENTRAL JUNCTION BOX (BEHIND LEFT END OF DASH) FUSE 11 FUSE 16 FUSE 24 GRY WIRE HOT AT ALL TIMES HOT IN RUN OR START IGNITION SWITCH INSTRUMENT CLUSTER LT BLU WIRE LT GRN WIRE O/D SWITCH ORG/ WIRE PARK PARK/ NEUTRAL POSITION SWITCH POWERTRAIN CONTROL MODULE IN RECESS ON UPPER CENTER OF FIREWALL) RED WIRE SHIFT LOCK SOLENOID TRANSMISSION RANGE SENSOR (ON LEFT SIDE OF TRANSMISSION) WHT WIRE YEL WIRE

A/T A/T M/T BATTERY BATTERY JUNCTION BOX (BJB) (LEFT FRONT CORNER OF ENG COMPT) BATTERY JUNCTION BOX (BJB) (LEFT FRONT CORNER OF ENGINE COMPT) FUSE 19 BLK WIRE BOX (CJB) (BELOW LEFT END OF DASH) CENTRAL JUNCTION CLUTCH CUT-OFF SWITCH (ON BRACKET, ABOVE CLUTCH PEDAL) DIODE DK BLU WIRE FUSE 11 HOLD HOT AT ALL TIMES IGNITION SWITCH LOCK LT BLU WIRE M/T NOT USED OFF ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PULL- IN RED WIRE RUN WIRE STARTER MOTOR STARTER RELAY TAN WIRE TAN/RED WIRE TRANSMISSION RANGE (TR) SENSOR (ON LEFT SIDE OF TRANSMISSION) WHT WIRE YEL WIRE

A/T A/T M/T BATTERY BATTERY JUNCTION BOX (BJB) (LEFT FRONT CORNER OF ENG COMPT) BATTERY JUNCTION BOX (BJB) (LEFT FRONT CORNER OF ENGINE COMPT) FUSE 19 BLK WIRE BOX (CJB) (BELOW LEFT END OF DASH) CENTRAL JUNCTION CLUTCH CUT-OFF SWITCH (ON BRACKET, ABOVE CLUTCH PEDAL) DIODE DK BLU WIRE FUSE 11 HOLD HOT AT ALL TIMES IGNITION SWITCH LOCK LT BLU WIRE M/T NOT USED OFF ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM PULL- IN RED WIRE RUN WIRE STARTER MOTOR STARTER RELAY TAN WIRE TAN/RED WIRE TRANSMISSION RANGE (TR) SENSOR (ON LEFT SIDE OF TRANSMISSION) WHT WIRE YEL WIRE

1 1 PASS SIDE AIR BAG FEED PASS SIDE AIR BAG RETURN 1 2 3 4 5 6 7 8 9 10 11 1 1 DRIVER SIDE AIR BAG FEED DRIVER SIDE AIR BAG RETURN AIR BAG INDICATOR AIR BAG INDICATOR CTRL GROUND DRIVER SAFETY BELT RETURN AIR BAG SLIDING CONTACT AIR BAG TONE DRIVER BLK WIRE BLK/YEL WIRE BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/YEL WIRE CENTRAL JUNCTION BOX (CJB) (BELOW LEFT END OF DASH) DATA LINK CONNECTOR (DLC) (PARTIAL) (ON LOWER LEFT SIDE OF DASH) DK GRN WIRE DRIVER AIR BAG UNIT DRIVER SAFETY BELT FEED DRIVER SEAT SEAT BELT TENSIONER FUSE GROUND GROUND IGNITION PASS SAFETY BELT FEED PASS SAFETY BELT RETURN GRY WIRE GRY/ORG WIRE GRY/WHT WIRE HOT IN RUN OR START INSTRUMENT CLUSTER LEFT SIDE AIR BAG MODULE LEFT SIDE AIR BAG SENSOR (AT BASE OF LEFT "B" PILLAR) LT BLU WIRE LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/PNK WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MICROPROCESSOR NCA WIRE ORG/ WIRE PASSENGER AIR BAG MODULE PASSENGER SEAT SEAT BELT TENSIONER PNK WIRE PNK/BLK WIRE RED WIRE RIGHT SIDE AIR BAG MODULE RIGHT SIDE AIR BAG SENSOR (AT BASE OF RIGHT "B" PILLAR) SHORTING BAR SOLID STATE VIO WIRE WHT WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
