Ford Escape I (2000-2004) 7 8 10 11 12 left sig out rt rear turn brake switch right sig out lft rear turn Wiring diagram
This page shows the only wiring diagram for the component.7 8 10 11 12 left sig out rt rear turn brake switch right sig out lft rear turn, which is found in the car Ford Escape I (2000-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 7 8 10 11 12 left sig out rt rear turn brake switch right sig out lft rear turn (1 of 1)
1 2 3 4 5 B+ LFT FRT TURN GRD RT FRT TURN FLASHER FEED
7 8 10 11 12 LEFT SIG OUT RT REAR TURN BRAKE SWITCH RIGHT SIG OUT LFT REAR TURN
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CENTRAL JUNCTION BOX (BELOW LEFT END OF DASH)
DK GRN WIRE
ELECTRONIC FLASHER MODULE (BEHIND LOWER LEFT END OF DASH)
FUSE 15
FUSE 20
FUSE 21
FUSE 24
FUSE 6
GENERIC ELECTRONIC MODULE (BEHIND LOWER CENTER OF DASH)
HAZARD FLASHER SWITCH
HIGH MOUNTED STOPLAMP (5)
HOT AT ALL TIMES
HOT W/ IGNITION RELAY ENERGIZED
INSTRUMENT CLUSTER
LEFT FRONT PARK/TURN LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR PARK/STOP LAMP
LEFT REAR TURN LAMP
LEFT SIDE TURN SIGNAL LAMP
LEFT TURN RIGHT TURN
LEFT TURN SIGNAL INDICATOR
LIGHT SWITCH
LT BLU WIRE
LT GRN WIRE
LT GRN/WHT WIRE
ORG/ WIRE
ORG/BLK WIRE
PARK LAMP RELAY
RED WIRE
RED/WHT WIRE
RIGHT FRONT PARK/TURN LAMP RIGHT REAR TURN LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR PARK/STOP LAMP
RIGHT SIDE TURN SIGNAL LAMP
RIGHT TURN SIGNAL INDICATOR
TRAILER TOW CONNECTOR
VIO WIRE
WHT WIRE
WHT/LT BLU WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> 7 8 10 11 12 LEFT SIG OUT RT REAR TURN BRAKE SWITCH RIGHT SIG OUT LFT REAR TURN
