Ford Escape I (2000-2004) 29 92 55 3 o/d sw bpp sw power ground wiring diagram

13 10 2 DATA LINK CONNECTOR (DLC) (ON LOWER LEFT SIDE OF DASH) 29 92 55 3 O/D SW BPP SW POWER GROUND BATTERY JUNCTION BOX (BJB) (ON LEFT FRONT CORNER OF ENGINE COMPT) BLK WIRE BLK/PNK WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH (ON BRACKET ABOVE BRAKE PEDAL) BRAKE SHIFT INTERLOCK RELAY, GEM, INSTRUMENT CLUSTER BRN/LT GRN WIRE BRN/WHT WIRE CCS SOLENOID CENTRAL JUNCTION BOX (BELOW LEFT END OF DASH) CENTRAL JUNCTION BOX (CJB) (BELOW LEFT END OF DASH) COOLING FAN RELAYS, A/C CLUTCH FAN RELAY DEACTIVATOR SWITCH DK BLU/YEL WIRE ELECTRONIC PRESSURE CONTROL SOLENOID ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE (ECT) SENSOR (REAR OF RIGHT CYLINDER HEAD) EXTERIOR LIGHTS SYSTEM (BACKUP LAMPS) FUSE 10 FUSE 16 FUSE 24 FUSE 4 FUSE 9 GRY/WHT WIRE HOT AT ALL TIMES HOT IN RUN OR START INSTRUMENT CLUSTER LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN WIRE LT GRN/RED WIRE MASS AIRFLOW (MAF) SENSOR (ON LEFT SIDE OF ENGINE COMPT, IN AIR INTAKE DUCT) ORG/ WIRE ORG/BLK WIRE ORG/YEL WIRE PCM POWER DIODE PCM POWER RELAY PNK/BLK WIRE PNK/LT BLU WIRE RED WIRE RED/LT GRN WIRE RED/YEL WIRE SHIFT INTERLOCK SYSTEM SHIFT SOLENOID A SHIFT SOLENOID B STARTING SYSTEM TAN/LT BLU WIRE TAN/ORG WIRE TAN/RED WIRE THROTTLE POSITION SENSOR (TPS) (ON THROTTLE BODY) TOP OF ENGINE) TORQUE CONVERTER CLUTCH SOLENOID TRANSMISSION FLUID TEMPERATURE SENSOR TRANSMISSION RANGE SENSOR (LEFT SIDE OF TRANSMISSION) TURBINE SHAFT SPEED SENSOR (TSS) (RIGHT REAR OF TRANSMISSION) VIO WIRE VIO/ORG WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
