Ford Escape I (2000-2004) 1 2 3 4 5 b+ lft frt turn grd rt frt turn flasher feed Wiring diagram

1 2 3 4 5 B+ LFT FRT TURN GRD RT FRT TURN FLASHER FEED 7 8 10 11 12 LEFT SIG OUT RT REAR TURN BRAKE SWITCH RIGHT SIG OUT LFT REAR TURN BLK WIRE BLK/WHT WIRE BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL) BRN WIRE CENTRAL JUNCTION BOX (BELOW LEFT END OF DASH) DK GRN WIRE ELECTRONIC FLASHER MODULE (BEHIND LOWER LEFT END OF DASH) FUSE 15 FUSE 20 FUSE 21 FUSE 24 FUSE 6 GENERIC ELECTRONIC MODULE (BEHIND LOWER CENTER OF DASH) HAZARD FLASHER SWITCH HIGH MOUNTED STOPLAMP (5) HOT AT ALL TIMES HOT W/ IGNITION RELAY ENERGIZED INSTRUMENT CLUSTER LEFT FRONT PARK/TURN LAMP LEFT LICENSE PLATE LAMP LEFT REAR PARK/STOP LAMP LEFT REAR TURN LAMP LEFT SIDE TURN SIGNAL LAMP LEFT TURN RIGHT TURN LEFT TURN SIGNAL INDICATOR LIGHT SWITCH LT BLU WIRE LT GRN WIRE LT GRN/WHT WIRE ORG/ WIRE ORG/BLK WIRE PARK LAMP RELAY RED WIRE RED/WHT WIRE RIGHT FRONT PARK/TURN LAMP RIGHT REAR TURN LAMP RIGHT LICENSE PLATE LAMP RIGHT REAR PARK/STOP LAMP RIGHT SIDE TURN SIGNAL LAMP RIGHT TURN SIGNAL INDICATOR TRAILER TOW CONNECTOR VIO WIRE WHT WIRE WHT/LT BLU WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE
