Car Wiring Diagrams for Telematics circuit for Ford Edge III (2023-2024)

BLK/BLU WIRE BLU/GRN WIRE BODY CONTROL MODULE (BCM) CELLULAR + CELLULAR SECOND + COAX COAX GPS COMPUTER DATA LINES SYSTEM FUSE 8 GATEWAY MODULE HOT AT ALL TIMES NCA WIRE PIFA ANTENNA SHARKFIN ANTENNA SPLITTER SYNC MODULE (APIM) TCU ENET - TELEMATICS CONTROL UNIT (TCU) MODULE VBATT VIO/RED WIRE VIO/WHT WIRE
