Active bodyworks circuit for Ford Edge III (2023-2024)
Active bodyworks circuit
2.0L TURBO
2.7L TURBO
ACTIVE GRILLE SHUTTER
BATTERY JUNCTION BOX (BJB)
BLK/GRN WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 11 FUSE 12
GRN/BLU WIRE
GRY WIRE
HOT W/ PCM RELAY ENERGIZED
INSTRUMENT PANEL CLUSTER (IPC)
LIN
POWERTRAIN CONTROL MODULE (PCM)
S135 (2.0L TURBO)
STARTING/ CHARGING SYSTEM
VPWR
WHT WIRE
WHT/GRN WIRE
