Ford Edge III (2023-2024) auto park Wiring diagrams
This page contains all the electrical diagrams for the component. auto park, in which he is found in the car Ford Edge III (2023-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram auto park (1 of 2)
ACTIVE PARK ASSIST SWITCH
AID SENS GND
APA ENABLE/
AUTO PARK
AUTO PARK IND (FET)
AUTO START STOP DEACTIVATION SWITCH
BLK/VIO WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/ORG WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DC/DC CONVERTER MODULE
DISABLE SW
FUSE 3
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRY/ORG WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HVAC MODULE (CENTER OF DASH)
ILLUM
IND (FET)
LEDS
LEFT FRONT ACTIVE PARK ASSIST SENSOR
LEFT FRONT INNER PARKING AID SENSOR
LEFT FRONT OUTER PARKING AID SENSOR
LF AUTO PARK SNS
LF INNER SNS
LF OUTER SNS
MICRO -
MS CAN +
PA ENABLE/
PARK AID
PARK AID IND OR STOP/START
PARK AID OR STOP/START
PWR IN
PWR OUT
REAR PARK
RED WIRE
RF AUTO PARK SNS
RF INNER SNS
RF OUTER SNS
RIGHT FRONT INNER PARKING AID SENSOR
RIGHT FRONT OUTER PARKING AID SENSOR
SOLID STATE
START/STOP DISABLE
START/STOP DISABLE SW
START/STOP IND
VIO/GRY WIRE
VIO/ORG WIRE
WHT/BLU WIRE
WHT/BRN WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit (2 of 2) -> AUTO PARK
Wiring diagram auto park (2 of 2)
2.0L TURBO 2.7L TURBO
AC-A
AC-B
ACTIVE PARK ASSIST SWITCH
ALTERNATING CURRENT (AC) POWER OUTLET SOCKET
AUTO
AUTO PARK
AUTO START STOP DEACTIVATION SWITCH
BACK- LIGHTING LED
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN WIRE
BUTTON LED (FET)
COMPUTER DATA LINES SYSTEM
DC/AC INVERTER MODULE
DO SPARE 3 (FET)
ENABLE/ DISABLE
FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 2 OF 7)
FROM BODY CONTROL MODULE (BCM) (DIAGRAM 3 OF 7)
FROM BODY CONTROL MODULE (BCM) (DIAGRAM 5 OF 7)
FROM KEYPAD ILLUM (FET) (DIAGRAM 4 OF 7)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRY WIRE
HOT
HVAC MODULE
LED
LEDS
LIN 4
MICRO -
NCA WIRE
NEUT
ORG/ WIRE
ORG/GRN WIRE
ORG/WHT WIRE
PARK AID IND OR START/ STOP IND
PARK AID OR START/STOP
PARK ENABLE/ DISABLE SW
POWERTRAIN CONTROL MODULE (PCM)
REAR PARKING AID CAMERA
RED WIRE
RUN WIRE
SMR
START CONTROL UNIT
START/ STOP 1
START/ STOP 1 (ACTIVE HIGH)
START/ STOP 2
START/ STOP 2 (ACTIVE LOW)
START/STOP DISABLE SW
START/STOP IND
START/STOP)
STATUS
VBATT
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ PARKING AID
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WIRELESS ACCESSORY CHARGING MODULE
YEL WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Power distribution circuit (6 of 7) -> AUTO PARK
