Car Wiring Diagrams for Defoggers circuit for Ford Edge II facelift (2018-2023)

BATTERY JUNCTION BOX (BJB) BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR MODULE (DDM) DRV HEATED FRONT CONTROLS INTERFACE MODULE (FCIM) FUSE 25 FUSE 26 FUSE 66 FUSE 68 GRN/VIO WIRE GRY WIRE GRY/ORG WIRE HEATED REAR WINDOW ELEMENT HEATED WIPER PARK HEATED WIPER PARK RELAY HOT AT ALL TIMES LEFT EXTERIOR MIRROR LIFTGATE MS CAN + PASS HEATED PASSENGER DOOR MODULE (PDM) REAR DEFROST REQUEST REAR WINDOW DEFROST RELAY RED WIRE RIGHT EXTERIOR MIRROR RUN/ START RELAY VBATT VIO/ORG WIRE VPWR WAVE TRAPPER WHT/ORG WIRE YEL WIRE YEL/RED WIRE
