Ford Edge II facelift (2018-2023) shift interlock override switch Wiring diagrams
This page contains all the electrical diagrams for the component. shift interlock override switch, in which he is found in the car Ford Edge II facelift (2018-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
shift interlock override switch wiring diagram (1 of 2)
ACTIVE PARK ASSIST SWITCH
AUDIO FRONT CONTROL MODULE (ACM)
AUTO START STOP DEACTIVATION SWITCH
BLK WIRE
BLOWER MOTOR CONTROL MODULE
BLU WIRE
CLOCKSPRING
CONSOLE FRONT AMBIENT LED
DOWNSHIFT PADDLE SWITCH
FLOOR CONSOLE CUP HOLDER AMBIENT LIGHTING LAMP
FLOOR CONSOLE STORAGE BIN AMBIENT LIGHTING LAMP
FRONT CONTROLS INTERFACE MODULE (FCIM)
FRONT POWER LIFTGATE SWITCH
FRONT POWER OUTLET SOCKET
FRONT POWER OUTLET SOCKET 2
GATEWAY MODULE A (GWM)
GEAR SHIFT MODULE (GSM)
GLOVE COMPARTMENT LAMP
GRN WIRE
GRY WIRE
HEADLAMP CONTROL MODULE (HCM)
HEADLAMP SWITCH
HEATED STEERING WHEEL MODULE (HSWM)
HORN SWITCH
IMAGE PROCESSING MODULE B (IPMB)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FOOTWELL LAMP
LEFT STEERING WHEEL SWITCH
LIFTGATE
NCA WIRE
PARKING BRAKE SWITCH
PASSENGER KNEE AIR BAG
REAR HEATED SEAT SWITCH
REAR PASSENGER POWER OUTLET SOCKET
REMOTE DATA LINK CONNECTOR (DLC)
RIGHT FOOTWELL LAMP
RIGHT STEERING WHEEL SWITCH
SHIFT INTERLOCK OVERRIDE SWITCH
START CONTROL UNIT
STEERING COLUMN CONTROL MODULE (SCCM)
STEERING COLUMN LOCK MODULE
SYNC MODULE (APIM)
UPSHIFT PADDLE SWITCH
VIO WIRE
W/ ADAPTIVE STEERING W/O ADAPTIVE STEERING
W/ AMBIENT LIGHTING
WIRELESS ACCESSORY CHARGING MODULE
Go to component -> Ground distribution circuit (2 of 5) -> SHIFT INTERLOCK OVERRIDE SWITCH
shift interlock override switch wiring diagram (2 of 2)
2.0L TURBO
2.0L TURBO 2.7L TURBO
2.7L TURBO
AJAR SW
BATTERY JUNCTION BOX (BJB)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
BPP
BPS
BRAKE PEDAL POSITION (BPP) SWITCH
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
DR LATCH SW
DR UNLOCK SW
DRIVER DOOR LATCH
FUSE 12
FUSE 54
GEAR SHIFT MODULE (GSM)
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT FRONT DOOR LOCK INDICATOR
MICRO -
OVERRIDE SW 1
OVERRIDE SW 2
PANEL)
PCAN +
POWERTRAIN CONTROL MODULE (PCM)
SHIFT INTERLOCK OVERRIDE SWITCH
SYSTEM
TRANS CAN - HS CAN -
TRANSMISSION ASSEMBLY
TRANSMISSION RANGE (TR) SENSOR
TRANSMISSIONS SYSTEM
TRGND
TRP 1
TRP 2
VBATT
VIO/ORG WIRE
VIO/WHT WIRE
VREF 2
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL/GRY WIRE
Go to component -> Shift interlock circuit -> SHIFT INTERLOCK OVERRIDE SWITCH
