Ford Edge II facelift (2018-2023) collapsible steering column module Wiring diagram
This page shows the only wiring diagram for the component.collapsible steering column module, which is found in the car Ford Edge II facelift (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram collapsible steering column module (1 of 1)
BLK/VIO WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRN/WHT WIRE
CASE GROUND
COLLAPSIBLE STEERING COLUMN MODULE
DRIVER KNEE AIR BAG
DRV AIR BAG 1 FEED
DRV AIR BAG 1 RTN
DRV AIR BAG 2 FEED
DRV AIR BAG 2 RTN
DRV FRONT CURTAIN SENS FEED
DRV FRONT CURTAIN SENS RTN
DRV STEERING COLUMN FEED
DRV STEERING COLUMN RTN
ENS
FUSE 14
FUSE 19
GRN/BLU WIRE
GRY/BLU WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
LEFT FRONT IMPACT SEVERITY SENSOR
MICRO -
NCA WIRE
PAD ADAPTIVE CAN VENT FEED
PAD ADAPTIVE CAN VENT RTN
PASS AIR BAG 1 FEED
PASS AIR BAG 1 RTN
PASS AIR BAG 2 FEED
PASS AIR BAG 2 RTN
PASS FRONT CURTAIN SENS FEED
PASS FRONT CURTAIN SENS RTN
PASS STEERING COLUMN FEED
PASS STEERING COLUMN RTN
PASSENGER KNEE AIR BAG
PASSENGER SIDE DOOR IMPACT SENSOR
RED WIRE
RESTRAINTS CONTROL MODULE (RCM)
RIGHT FRONT IMPACT SEVERITY SENSOR
SHORTING BAR
STEERING COLUMN FEED
STEERING COLUMN RTN
VBATT INPUT
VIO WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Supplemental restraints circuit (1 of 4) -> COLLAPSIBLE STEERING COLUMN MODULE
