Car Wiring Diagrams for Power liftgate circuit for Ford Edge II (2015-2018)

BATTERY JUNCTION BOX (BJB) BEHIND LEFT QUARTERPANEL) BLK/BLU WIRE BLK/VIO WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN WIRE BRN/BLU WIRE CAN (-) CAN (+) CINCH COMPUTER DATA LINES SYSTEM FRONT POWER LIFTGATE SWITCH FUSE 10 FUSE 76 GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY/ORG WIRE GRY/YEL WIRE HANDS FREE LIFTGATE ACTUATION MODULE HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) LEFT LIFTGATE ANTI PINCH STRIP LH PINCH STRIP SIG LIFTGATE AJAR LIFTGATE RELEASE LIFTGATE RELEASE SWITCH LIFTGATE/LUGGAGE COMPARTMENT LID LATCH MICRO - MOTOR CLOSE, MOTOR OPEN, MS CAN + NCA WIRE OPEN SESAME INPUT ORG/ WIRE OUTPUT PAWL SIG PAWL/AJAR PINCH STRIP RTN POSITION SENSOR POWER LIFTGATE MOTOR (LEFT "D" PILLAR) PRIMARY PRIMARY RATCHET SIG SECONDARY RATCHET SIG PWR MTR- RATCHET REAR GATE TRUNK MODULE (RGTM) REAR INTERIOR SW REAR POWER LIFTGATE SWITCH RELEASE RELEASE MTR RH PINCH STRIP SIG LIFTGATE AJAR RIGHT LIFTGATE ANTI PINCH STRIP SECONDARY SENSOR PWR SENSOR PWR SENSOR RTN SENSOR RTN SENSOR SIG 1 SENSOR SIG 2 SIG UNCINCH VBATT VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE ZERO POSITION ZERO POSITION SIG CONSOLE OPEN/ CLOSE SW
