Car Wiring Diagrams for Charging circuit for Ford Edge II (2015-2018)

2.0L TURBO 2.7L TURBO 3.5L BATT MONITOR BATTERY BATTERY CURRENT SENSOR BATTERY JUNCTION BOX (BJB) BATTERY MONITORING SENSOR BLK/VIO WIRE BLK/YEL WIRE BLU/ORG WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) BRN/VIO WIRE COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM FUSE 2 FUSE 55 FUSE 8 GENERATOR B+ GENERATOR CURRENT SENSOR GENLI GENRC GRN/BLU WIRE GRN/RED WIRE GRN/VIO WIRE GRY/BRN WIRE HIGH CURRENT BATTERY JUNCTION BOX (BJB) INSTRUMENT PANEL CLUSTER (IPC) LI RC BVS MICRO - MON NCA WIRE POWERTRAIN CONTROL MODULE (PCM) RED WIRE SEN+ SIG RTN STARTER MOTOR VIO WIRE VIO/GRN WIRE VREF W/O STOP/START W/ STOP/START WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL/RED WIRE YEL/VIO WIRE
