Ford Edge II (2015-2018) pass vbatt Wiring diagram
This page shows the only wiring diagram for the component.pass vbatt, which is found in the car Ford Edge II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass vbatt (1 of 1)
BATTERY JUNCTION BOX (BJB)
BLK/GRY WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (BCM)
DRV HIGH SW
DRV VBATT
FUSE 36
FUSE 73
GRN WIRE
GRN/BRN WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
ILLUM
LED
LEFT HIGH IND
LEFT LOW IND
LEFT REAR SEAT BACKREST HEATER MAT
LEFT REAR SEAT CUSHION HEATER MAT
LEFT SWITCH
LR HEATER FD
LR SEAT NTC
NCA WIRE
PASS HIGH IND
PASS HIGH SW
PASS LOW IND
PASS VBATT
POWER DISTRIBUTION SYSTEM
REAR HEATED SEAT MODULE
REAR HEATED SEAT SWITCH
RED WIRE
RETURN
RIGHT HIGH IND
RIGHT LOW IND
RIGHT REAR SEAT BACKREST HEATER MAT
RIGHT REAR SEAT CUSHION HEATER MAT
RIGHT SWITCH
RR HEATER FD
RR HIGH/OFF
RR LOW/OFF
RR SEAT NTC
VIO WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VPWR
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/ORG WIRE
Go to component -> Rear heated seats circuit -> PASS VBATT
