Ford Edge II (2015-2018) boost enable Wiring diagrams
This page contains all the electrical diagrams for the component. boost enable, in which he is found in the car Ford Edge II (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram boost enable (1 of 2)
2.0L TURBO
AUDIO FRONT CONTROL MODULE (ACM)
AUTO PARK IND (FET)
BATT PWR
BLK WIRE
BLU WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
BOOST ENABLE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MODULE (C-CM)
FROM BATTERY JUNCTION BOX (BJB) (DIAGRAM 3 OF 7)
FROM HIGH CURRENT BATTERY JUNCTION BOX (BJB) (DIAGRAM 1 OF 7)
FRONT CONTROL/ DISPLAY INTERFACE MODULE (FCDIM)
FRONT CONTROLS INTERFACE MODULE (FCIM)
FRONT PARKING AID CAMERA
FUSE 12
FUSE 13
FUSE 32
FUSE 33
GATEWAY MODULE A (GWM)
GLOBAL POSITIONING SYSTEM MODULE (GPSM)
GRN WIRE
GRY WIRE
HEAD-UP DISPLAY (HUD) MODULE
IMAGE PROCESSING MODULE B (IPMB)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L)
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
MICRO -
NCA WIRE
PARK AID IND (FET)
POWERTRAIN CONTROL MODULE (PCM)
PWR LOGIC RLY
RADIO TRANSCEIVER MODULE (RTM)
REAR PARKING AID CAMERA
RED WIRE
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R)
RUN/START (FET)
STEERING COLUMN CONTROL MODULE (SCCM)
SYNC MODULE (APIM)
TO BATTERY JUNCTION BOX (BJB) (DIAGRAM 2 OF 7)
VBATT
VIO WIRE
VPWR
W/ STOP/ START
W/ STOP/START
W/ TOUCH SCREEN W/O TOUCH SCREEN
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component -> Power distribution circuit (6 of 7) -> BOOST ENABLE
Wiring diagram boost enable (2 of 2)
2.0L TURBO
2.7L TURBO
3.5L
BATT PWR
BATTERY JUNCTION BOX (BJB)
BLK WIRE
BLK/VIO WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BOOST ENABLE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FRONT CONTROLS INTERFACE MODULE (FCIM)
FUSE 23
FUSE 3
GRY/ORG WIRE
HIGH CURRENT BATTERY JUNCTION BOX (BJB)
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY
LEDS
LOW VOLTAGE DIRECT CURRENT/ DIRECT CURRENT (DC/DC) CONVERTER
MS CAN +
OSS/TR GND
OSS/TR VPWR
POWER DISTRIBUTION SYSTEM
POWERTRAIN CONTROL MODULE (PCM)
PWR LOGIC RLY
RED WIRE
S161 (2.7L TURBO) S169 (3.5L)
SMC
SMCS
SME
START STOP
START/STOP DISABLE SW
START/STOP IND
TR 1
TR 2
TR 3
TR 4
TR GND
TR-P
TRANSMISSIONS SYSTEM
TRS
TSS/OSS/TR GND
TSS/OSS/TR VPWR
VBATT
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VPWR
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> Starting circuit (2 of 2) -> BOOST ENABLE
