Wiring Diagrams for Ford Edge II (2015-2018)

Automatic a/c circuit Manual a/c circuit

Anti-lock brakes circuit

Anti-theft circuit

Body control modules circuit

Computer data lines circuit

Cooling fan circuit

Cruise control circuit

Defoggers circuit

Adaptive steering circuit Electronic power steering circuit

Wiring diagram engine performance 2.0l turbo

Wiring diagram engine performance 2.7l turbo

Wiring diagram engine performance 3.5l

Backup lamps circuit Exterior lamps circuit Trailer adapter circuit

Ground distribution circuit

Headlights circuit

Horn circuit

Instrument cluster circuit Overhead console circuit

Courtesy lamps circuit Instrument illumination circuit

Driver"s memory seat circuit Memory mirrors circuit Steering column memory circuit

Blind spot information system circuit Navigation circuit, w/o sony w/ touch screen Navigation circuit, w/o touch screen Navigation circuit, w/ sony & touch screen Parking assistant circuit Rear camera circuit, w/o touch screen Rear camera circuit, w/ touch screen & front camera Rear camera circuit, w/ touch screen w/o front camera

Power distribution circuit

Power door locks circuit

Electrochromic mirror circuit, w/ automatic wiper Electrochromic mirror circuit, w/o automatic wiper Power mirrors circuit

Climate control seats circuit Driver power seat circuit Front heated seats circuit Heated steering wheel circuit Passenger power seat circuit, 10-way Passenger power seat circuit, 6-way Passenger power seat circuit, 8-way Rear heated seats circuit Second row seat release circuit

Power top/sunroof circuit

Power windows circuit

Radio circuit, w/o sony w/ touch screen Radio circuit, w/o touch screen Radio circuit, w/ sony & touch screen

Shift interlock circuit

Charging circuit Starting circuit

Supplemental restraints circuit

2.0l turbo, a/t circuit 2.0l turbo, awd circuit

2.7l turbo, a/t circuit 2.7l turbo, awd circuit

3.5l, a/t circuit 3.5l, awd circuit

Liftgate release circuit Power liftgate circuit

Chime circuit Tire pressure monitoring circuit

Wiper/washer circuit

ANTI-LOCK BRAKES SYSTEM ANTI-LOCK BRAKES, INSTRUMENT CLUSTER SYSTEMS BATTERY SAVER CENTRAL LOCK RLY CHILD LOCK RLY GENERATOR B+ HIGH CURRENT BATTERY JUNCTION BOX HORN RLY IN HORN RLY INPUT HORN SW IGNITION COIL ON PLUG 1 IGNITION COIL ON PLUG 2 IGNITION COIL ON PLUG 3 IGNITION COIL ON PLUG 4 IGNITION COIL ON PLUG 5 IGNITION COIL ON PLUG 6 LOCK OUT STEERING COLUMN LOCK MODULE

(RIGHT FRONT OF ENGINE AIR DISTRIBUTION DOOR ACTUATOR AIR INLET DOOR ACTUATOR BLOWER MOTOR COOLING FAN MOTOR 1 COOLING FAN MOTOR 2 ENGINE CONTROLS SYSTEM LEFT FRONT SEAT BACKREST BLOWER MOTOR LEFT FRONT SEAT CUSHION BLOWER MOTOR LEFT FRONT SEAT HEIGHT ADJUSTMENT MOTOR LEFT FRONT SEAT RECLINER MOTOR LEFT FRONT SEAT TILT MOTOR LEFT FRONT SEAT TRACK MOTOR LEFT PARKING BRAKE ACTUATOR MOTOR LEFT SECOND ROW SEAT MOTOR LEFT TEMPERATURE DOOR ACTUATOR LEFT WINDSHIELD WIPER MOTOR LOWER RIGHT FRONT OF ENGINE) MOTOR CLOSE, MOTOR OPEN, REAR WINDOW WIPER MOTOR RIGHT FRONT SEAT BACKREST BLOWER MOTOR RIGHT FRONT SEAT CUSHION BLOWER MOTOR RIGHT FRONT SEAT HEIGHT ADJUSTMENT MOTOR RIGHT FRONT SEAT RECLINER MOTOR RIGHT FRONT SEAT TILT MOTOR RIGHT FRONT SEAT TRACK MOTOR RIGHT PARKING BRAKE ACTUATOR MOTOR RIGHT SECOND ROW SEAT MOTOR RIGHT TEMPERATURE DOOR ACTUATOR RIGHT WINDSHIELD WIPER MOTOR ROOF OPENING PANEL MOTOR ASSEMBLIES STARTER MOTOR STEERING COLUMN TELESCOPIC MOTOR STEERING COLUMN TILT MOTOR

ANTENNA PWR CENTER PASSIVE ANTI-THEFT SYSTEM ANTENNA INTERNAL ANTENNA RKE RECEIVER REAR PASSIVE ANTI-THEFT SYSTEM ANTENNA

DRIVER DOOR WINDOW REGULATOR MOTOR LEFT REAR DOOR WINDOW REGULATOR MOTOR PASSENGER DOOR WINDOW REGULATOR MOTOR RIGHT REAR DOOR WINDOW REGULATOR MOTOR

CAMERA WINDSHIELD DEFROST HEATER FRONT PARKING AID CAMERA REAR CAMERA CIRCUIT REAR PARKING AID CAMERA REAR PARKING AID CAMERA SHIELD

FRONT POWER OUTLET SOCKET FRONT POWER OUTLET SOCKET 2 LUGGAGE COMPARTMENT POWER OUTLET SOCKET REAR PASSENGER POWER OUTLET SOCKET TRAILER TOW CONNECTOR TRAILER TOW SOCKET

BATTERY ENERGY CONTROL MODULE B BLOWER MOTOR CONTROL MODULE FUEL PUMP CONTROL MODULE FUEL PUMP CONTROL MODULE SHIELD HOT W/ POWERTRAIN CONTROL MODULE POWER RELAY ENERGIZED STEERING COLUMN CONTROL MODULE

FUEL PUMP, SENDER UNIT FUEL PUMP, SENDER UNIT SHIELD START CONTROL UNIT TRANSFER UNIT OIL COOLING FAN

FUSE 1 FUSE 2 FUSE 3 FUSE 5 FUSE 6 FUSE 7 FUSE 8 FUSE 9 FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 26 FUSE 27 FUSE 28 FUSE 29 FUSE 30 FUSE 32 FUSE 33 FUSE 34 FUSE 36 FUSE 37 FUSE 38 FUSE 43 FUSE 44 FUSE 48 FUSE 50 FUSE 54 FUSE 55 FUSE 58 FUSE 59 FUSE 60 FUSE 62 FUSE 63 FUSE 65 FUSE 66 FUSE 67 FUSE 68 FUSE 69 FUSE 70 FUSE 72 FUSE 73 FUSE 74 FUSE 75 FUSE 76 FUSE 77 FUSE 78 FUSE 79 FUSE 80 FUSE 81 FUSE 84 FUSE 87 MEGA FUSE 1 MEGA FUSE 2 MEGA FUSE 3 MEGA FUSE 6 MEGA FUSE 8

DRV HEATER FEED LEFT FRONT SEAT BACKREST HEATER MAT LEFT FRONT SEAT CUSHION HEATER MAT LEFT REAR SEAT BACKREST HEATER MAT LEFT REAR SEAT CUSHION HEATER MAT LR HEATER FD PASS HEATER FEED RIGHT FRONT SEAT BACKREST HEATER MAT RIGHT FRONT SEAT CUSHION HEATER MAT RIGHT REAR SEAT BACKREST HEATER MAT RIGHT REAR SEAT CUSHION HEATER MAT RR HEATER FD

BLIS INDICATOR LEFT FRONT DOOR LOCK INDICATOR LEFT REAR DOOR LOCK INDICATOR LOW BRAKE FLUID WARNING INDICATOR SWITCH LOW WASHER FLUID WARNING INDICATOR SWITCH RIGHT FRONT DOOR LOCK INDICATOR RIGHT REAR DOOR LOCK INDICATOR

FLOOR CONSOLE CUP HOLDER AMBIENT LIGHTING LAMP FLOOR CONSOLE LAMP FLOOR CONSOLE STORAGE BIN AMBIENT LIGHTING LAMP GLOVE COMPARTMENT LAMP HIGH MOUNTED STOP LAMP INTERIOR LIGHTS SYSTEM SHIFT INTERLOCK SYSTEM LAMP DIMMING LEFT FOOTWELL LAMP LEFT REAR INTERIOR LAMP LEFT REAR LAMP ASSEMBLY LEFT SCUFF PLATE LAMP LEFT SIGNATURE LAMP LEFT VANITY MIRROR LAMP LET REAR LAMP ASSEMBLY LICENSE PLATE LAMP LUGGAGE COMPARTMENT LAMP REVERSING LAMP RIGHT FOOTWELL LAMP RIGHT REAR INTERIOR LAMP RIGHT REAR LAMP ASSEMBLY RIGHT SCUFF PLATE LAMP RIGHT SIGNATURE LAMP RIGHT VANITY MIRROR LAMP SECOND ROW INTERIOR LAMP

CABIN HEATER COOLANT PUMP FUEL INJECTION PUMP TRANSMISSION FLUID PUMP WINDSHIELD WASHER PUMP

ACCESSORY DELAY RELAY AIR CONDITION CLUTCH RELAY BATT SAVER RELAY BATTERY SAVER RELAY BLOWER MOTOR RELAY BLOWER RELAY CENTRAL LOCK RELAY CENTRAL UNLOCK RELAY CHILD LOCK RELAY DECKLID/ LIFT GATE RELAY DECKLID/ LIFTGATE RELAY DOUBLE/ AUX LOCK RELAY DRIVER/ FUEL FLAP UNLOCK RELAY FUEL PUMP RELAY HEATED WIPER PARK RELAY HORN RELAY HOT W/ ACCESSORY DELAY RELAY ENERGIZED HOT W/ IGNITION RELAY ENERGIZED HOT W/ RUN/ START RELAY ENERGIZED HOT W/ RUN/START RELAY ENERGIZED LATCHING POWER POINT RELAY 1 LATCHING POWER POINT RELAY 2 REAR WASHER RELAY REAR WINDOW DEFROST RELAY RUN/ START RELAY RUN/START RELAY SECOND ROW SEAT RELAY STARTER RELAY STEERING COLUMN LOCK RELAY WIPER RELAY

AUTOLAMP SENSOR INPUT AUTOLAMP SENSOR RETURN BATTERY CURRENT SENSOR BATTERY MONITORING SENSOR BRAKE VACUUM SENSOR CRANKCASE PRESSURE SENSOR CYLINDER HEAD TEMPERATURE SENSOR DRIVER SIDE DOOR IMPACT SENSOR EVAPORATOR TEMPERATURE SENSOR FUEL LEVEL SENSOR FUEL PRESSURE SENSOR GENERATOR CURRENT SENSOR HALL SENSOR 1 HALL SENSOR 1 HALL SENSOR SUPPLY HALL SENSOR 2 HALL SENSOR GND HALL SENSOR SUPPLY IN-VEHICLE TEMPERATURE/ HUMIDITY SENSOR LEFT FOOTWELL AIR DISCHARGE TEMPERATURE SENSOR LEFT FRONT ACTIVE PARK ASSIST SENSOR LEFT FRONT IMPACT SEVERITY SENSOR LEFT FRONT INNER PARKING AID SENSOR LEFT FRONT OUTER PARKING AID SENSOR LEFT FRONT WHEEL SPEED SENSOR LEFT REAR ACTIVE PARK ASSIST SENSOR LEFT REAR OUTER PARKING AID SENSOR LEFT REAR WHEEL SPEED SENSOR LEFT REGISTER AIR DISCHARGE TEMPERATURE SENSOR LEFT SEAT POSITION SENSOR LEFT SIDE "C" PILLAR IMPACT SENSOR LEFT/CENTER REAR INNER PARKING AID SENSOR LF SENSOR HI LF SENSOR LO LR SENSOR HI LR SENSOR LO PASSENGER SIDE DOOR IMPACT SENSOR POSITION SENSOR RAIN SENSOR RF SENSOR HI RF SENSOR LO RIGHT FOOTWELL AIR DISCHARGE TEMPERATURE SENSOR RIGHT FRONT ACTIVE PARK ASSIST SENSOR RIGHT FRONT IMPACT SEVERITY SENSOR RIGHT FRONT INNER PARKING AID SENSOR RIGHT FRONT OUTER PARKING AID SENSOR RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR ACTIVE PARK ASSIST SENSOR RIGHT REAR INNER PARKING AID SENSOR RIGHT REAR OUTER PARKING AID SENSOR RIGHT REAR WHEEL SPEED SENSOR RIGHT REGISTER AIR DISCHARGE TEMPERATURE SENSOR RIGHT SEAT POSITION SENSOR RIGHT SIDE "C" PILLAR IMPACT SENSOR RR SENSOR HI RR SENSOR LO SENSOR PWR SENSOR PWR SENSOR RTN SENSOR RTN SENSOR SIG 1 SENSOR SIG 2 TRANSFER CASE FLUID TEMPERATURE SENSOR WASTEGATE VACUUM SENSOR

INSTRUMENT PANEL SPEAKER LEFT FRONT DOOR SPEAKER LEFT FRONT DOOR TWEETER SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR DOOR TWEETER SPEAKER LEFT REAR QUARTER PANEL SPEAKER REAR CENTER SPEAKER RIGHT FRONT DOOR SPEAKER RIGHT FRONT DOOR TWEETER SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR DOOR TWEETER SPEAKER RIGHT REAR QUARTER PANEL SPEAKER

DOWNSHIFT PADDLE SWITCH DRIVER BUCKLE SWITCH DRIVER DOOR WINDOW CONTROL SWITCH DRIVER SAFETY BELT BUCKLE SWITCH EXTERIOR REAR VIEW MIRROR SWITCH FRONT POWER LIFTGATE SWITCH HEADLAMP SWITCH HEATED REAR SEAT SWITCH HOOD AJAR SWITCH HORN SWITCH INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY LEFT FRONT DOOR LOCK SWITCH LEFT FRONT SEAT CONTROL SWITCH LEFT REAR DOOR WINDOW CONTROL SWITCH LEFT SECOND ROW SEAT CONTROL SWITCH LEFT STEERING WHEEL SWITCH LEFT SWITCH LIFTGATE RELEASE SWITCH MEMORY SET SWITCH MULTI- FUNCTION SWITCH PARKING BRAKE SWITCH PASSENGER DOOR WINDOW CONTROL SWITCH REAR HEATED SEAT SWITCH REAR POWER LIFTGATE SWITCH RIGHT FRONT DOOR LOCK SWITCH RIGHT FRONT SEAT CONTROL SWITCH RIGHT REAR DOOR WINDOW CONTROL SWITCH RIGHT STEERING WHEEL SWITCH RIGHT SWITCH UPSHIFT PADDLE SWITCH

OIL PRESSURE CONTROL SOLENOID

(OR RED/ WIRE BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE NCA WIRE ORG/ WIRE ORG/GRN WIRE ORG/WHT WIRE PNK WIRE RED WIRE TAN WIRE VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/RED WIRE YEL/VIO WIRE

1/2 3/4 2.0L TURBO 2.0L TURBO 2.7L TURBO 2.0L TURBO 2.7L TURBO 3.5L 2.7L TURBO 2.7L TURBO 2.0L TURBO 3.5L 3.5L 2.0L TURBO 2.7L TURBO 3.5L 2.7L TURBO, 2.0L TURBO 3.5L, 2.7L TURBO 8 WAY POWER SEAT 6, 10 WAY POWER SEAT (OR A/D CHANNEL 1 A/D CHANNEL 2 A/D CHANNEL 3 A/D CHANNEL 4 A/D RETURN A/D RTN AC-A AC-B ACTIVE GRILLE SHUTTER ACTIVE PARK ASSIST SW AFT FORE/ AIR CONDITIONING SYSTEM AM/FM SIG AMBIENT LIGHTING AMBIENT NOISE 1 - AMBIENT NOISE 2 - AMBIENT NOISE 3 - ANTI-THEFT, WARNING SYSTEMS ATCC SOL - AUDIO ENABLE AUDIO IN LEFT- AUDIO IN RIGHT- AUTO DIMMING INTERIOR MIRROR AUTO PARK AUTOLAMP DAY/NIGHT SENS + LIN 2 AWD-C AWD-M BACKUP LAMPS CIRCUIT BASE BACKWARD BASE FORWARD BATT MONITOR BATT PWR BATT VQM BUS PWR BEHIND LEFT QUARTERPANEL) BLIS IND BLOWER CONTROL BOOST ENABLE BRAKE FLUID SW BRK FLUID BRK FLUID LVL SW BTS SIG BTS VREF BUCKLE SW CANCEL GAP DOWN CASE GND CASE GROUND CHARGING CIRCUIT CHARGING SYSTEM CIRCUIT BREAKER 38 CLOCK- SPRING COAXIAL CABLE COLLAPSIBLE STEERING COLUMN MODULE COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM CRUISE CONTROL SYSTEM CRUISE CONTROL, NAVIGATION, SOUND SYSTEMS DATA LINES DBKTED- DBLWR+ DCSHTED- DECKLID AJAR SW DECKLID/LIFTGATE RLY DEFOGGER SYSTEM DEFROST REQUEST DIM + DIM+ CAN+ DIM- DIMMER IP/SW ILL DIM DOWN DIMMER IP/SW ILL DIM UP DM GND DM PWR DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS DOOR LOCKS, ANTI-THEFT, WARNING SYSTEMS DRIVER AIR BAG DRIVER DOOR LATCH DRIVER KNEE AIR BAG DRIVER SAFETY BELT BUCKLE DRIVER SAFETY BELT RETRACTOR PRETENSIONER DRIVER SIDE AIR BAG DRIVER TRACK POS DRV AIR BAG 1 FEED DRV AIR BAG 1 RTN DRV AIR BAG 2 FEED DRV AIR BAG 2 RTN DRV BUCKLE SW DRV CURTAIN FEED DRV CURTAIN RTN DRV FRONT CURTAIN SENS FEED DRV FRONT CURTAIN SENS RTN DRV HEATED DRV HIGH SW DRV MIRR HORZ POT DRV MIRR MTR DOWN/RIGHT DRV MIRR VERT POT DRV MIRROR MTR LEFT DRV MIRROR MTR VERT UP DRV PRETENSIONER FEED DRV PRETENSIONER RTN DRV PUDDLE DRV RETRACTOR PRETESIONER + DRV ROW 2 IMPACT SENS FEED DRV ROW 2 IMPACT SENS RTN DRV SIDE AIR BAG FEED DRV SIDE AIR BAG RTN DRV SIDE IMPACT SENS FEED DRV SIDE IMPACT SENS RTN DRV ST NTC SENSE DRV STEERING COLUMN FEED DRV STEERING COLUMN RTN DRV SUNLOAD DRV TRACK POSITION DRV TURN DRV VBATT ELECTROCHROMIC MIRROR CIRCUIT ENG SW ETC REF ETCRTN TSS/OSS/TR GND ETCRTN TSS/OSS/TR GND MAP EXT MIRR POT FEED EXTERNAL CONTROL 1 FAPA SENS LH IN FAPA SENS RH IN FC SPKR + FIL SENS LH IN FIR SENS RH IN FLOOR SHIFTER FOL SENS LH IN FOLD OUT FOLD-IN FOR SENS RH IN FP PWR FP RTN FRONT DN FRONT HEIGHT FRONT UP FRT WIPER HI FUEL INJECTOR 1 FUEL INJECTOR 2 FUEL INJECTOR 3 FUEL INJECTOR 4 FUEL INJECTOR 5 FUEL INJECTOR 6 FUEL SENDER 1 FUEL SENDER 1 RTN FUEL SENDER 2 FUEL SENDER 2 RTN FUEL SNDR 1 GAP UP GATEWAY MODULE GUARD TRACK HALF BRIDGE HALL EFFECT RTN HALL EFFECT SENS HANDS FREE LIFT GATE ACTUATION MODULE HANDS FREE LIFTGATE ACTUATION MODULE HAZARD SW HEADLAMP LEVELING HEADLAMP OFF HEADLAMP OFF SW HEADLAMP ON HEADLAMP ON SW HEADLAMP PARK ON OFF HEADLIGHTS SYSTEM HEATED REAR PARK HEATED REAR WINDOW ELEMENT HEATED WIPER PARK HIGH BEAM HLL OUT HOMELINK MODULE HOOD AJAR HOOD AJAR SW HORNS SYSTEM HOT AT ALL TIMES HOT W/ HS CAN+ HTR RTN HUMIDITY MTR HUMIDITY SIG ID-LO ILLUM GND ILLUMINATION GND IN VEHICLE SIG IN VEHICLE SIG DRV ST NTC SENS INJ 1 INJ 2 INJ 3 INJ 4 INJ 5 INJ 6 ISP-R K LINE K- BUS KEY- KEY- KEY- PAD PAD PAD KEYLESS ENTRY KEYPAD KEYLESS KEYPAD LINE A SW KEYLESS KEYPAD LINE B SW KEYLESS KEYPAD LINE C SW LATCH GND LCK STATUS LEFT EXTERIOR MIRROR LEFT FRONT EXTERIOR DOOR HANDLE LEFT FRONT SAFETY BELT ANCHOR, PRETENSIONER LEFT FRONT SEAT AMBIENT LIGHTING LEFT FRONT SEAT POWER LUMBAR ASSEMBLY LEFT HEADLAMP ASSEMBLY LEFT HIGH IND LEFT LIFTGATE ANTI PINCH STRIP LEFT LOW IND LEFT REAR DOOR LATCH LEFT REAR DOWN LEFT REAR EXTERIOR DOOR HANDLE LEFT REAR HEATED SEAT MODULE LEFT REAR UP LEFT SECOND ROW SAFETY BELT LEFT SECOND ROW SAFETY BELT BUCKLE LEFT SEEK LEFT SIDE AIR CURTAIN LEFT TURN LF ACTIVE PRK ASSIST SENS IN LF AMBIENT NOISE 1 + LF DOOR LF DOOR AJAR LF DR AJAR LF NOISE CANCEL + LF SPKR LF TWEETER+ LH PINCH STRIP SIG LI RC BVS LIFTGATE AJAR LIFTGATE RELEASE LIFTGATE/ LUGGAGE COMPARTMENT LID LIFTGATE/DECKLID RELEASE AJAR LIFTGATE/LUGGAGE COMPARTMENT LID LIFTGATE/LUGGAGE COMPARTMENT LID LATCH LIN 2 LIN 4 LIN BUS LOGIC GND LOW BEAM LOW SERIES HIGH SERIES LOW WASHER LR ACTIVE PRK ASSIST SENS LR DOOR LR DOOR AJAR LR DR AJAR LR SEAT NTC LR SPKR LT FRT SENS 1 LT FRT SENS 2 LTCH GND LVL SW MANUAL A/C AUTOMATIC A/C MEDIA BIN AMBIENT LED MEDIA GND MEMORY SYSTEMS MIC - MICRO - MIRRORS SYSTEM MS CAN + MTR A EPB LT MTR A EPB RT 3 4 MTR B EPB RT MTR B EPB LT NAVIGATION SYSTEM NAVIGATION, SOUND SYSTEMS NOISE CANCELLATION MICROPHONE 1 NOISE CANCELLATION MICROPHONE 2 NOISE CANCELLATION MICROPHONE 3 NOT USED NOT USED NOT USED OCS OUT OPEN SESAME INPUT OSS + OSS/ TR GND OSS/TR GND OSS/TR VPWR OUTAGE TURN OUTAGE TURN SIDE MARKER PARK OVERHEAD CONSOLE PARK AID PARK DETECT PARK LP PARKING AID SW PASS ADAPTIVE LOAD LIMITER FEED PASS ADAPTIVE LOAD LIMITER RTN PASS AIR BAG 1 FEED PASS AIR BAG 1 RTN PASS AIR BAG 2 FEED PASS AIR BAG 2 RTN PASS BUCKLE SW PASS CURTAIN FEED PASS CURTAIN RTN PASS FRONT CURTAIN SENS FEED PASS FRONT CURTAIN SENS RTN PASS HEATED PASS HIGH IND PASS HIGH SW PASS LOW IND PASS MIRR HORZ POT PASS MIRR MTR DOWN/RIGHT PASS MIRR MTR VERT UP PASS MIRR VERT POT PASS MIRROR MTR LEFT PASS PRETENSIONER FEED PASS PRETENSIONER RTN PASS PUDDLE PASS RETRACTOR PRETESIONER - PASS ROW 2 IMPACT SENS FEED PASS ROW 2 IMPACT SENS RTN PASS SIDE AIR BAG FEED PASS SIDE AIR BAG RTN PASS SIDE IMPACT SENS FEED PASS SIDE IMPACT SENS RTN PASS ST NTC SENS PASS ST NTC SENSE PASS STEERING COLUMN FEED PASS STEERING COLUMN RTN PASS SUNLOAD PASS TRACK POSITION PASS TURN PASS VBATT PASSENGER DOOR LATCH PASSENGER KNEE AIR BAG PASSENGER SAFETY BELT BUCKLE PASSENGER SAFETY BELT LOAD LIMITING RETRACTOR PASSENGER SAFETY BELT RETRACTOR PRETENSIONER PASSENGER SIDE AIR BAG PAWL SIG PBKTED- PBLWR+ PCSHTED- PINCH STRIP RTN POWER DISTRIBUTION SYSTEM POWER TOPS SYSTEM POWER WINDOWS SYSTEM POWERTRAIN CONTROL PR DOOR PRIMARY RATCHET SIG SECONDARY RATCHET SIG PRK DETECT PWM IN PWR GND PWR LOGIC RLY PWR MTR- RAPA SENS LH IN RAPA SENS RH IN RC SPKR - RCM OUT REAR DEFROST REQUEST REAR DN REAR HEATED SEAT MODULE REAR HEIGHT REAR INTERIOR SW REAR LEFT DOWN REAR UP REAR WIPER RELEASE MTR RES+ RESET+ RF ACTIVE PRK ASSIST SENS IN RF AMBIENT NOISE 2 - RF DOOR RF DOOR AJAR RF DR AJAR RF NOISE CANCEL - RF SPKR RF TWEETER - RH PINCH STRIP SIG LIFTGATE AJAR RIGHT EXTERIOR MIRROR RIGHT FRONT EXTERIOR DOOR HANDLE RIGHT FRONT SAFETY BELT ANCHOR, PRETENSIONER RIGHT FRONT SEAT AMBIENT LIGHTING RIGHT FRONT SEAT POWER LUMBAR ASSEMBLY RIGHT HEADLAMP ASSEMBLY RIGHT HIGH IND RIGHT LIFTGATE ANTI PINCH STRIP RIGHT LOW IND RIGHT REAR DOOR LATCH RIGHT REAR EXTERIOR DOOR HANDLE RIGHT REAR UP RIGHT SECOND ROW SAFETY BELT RIGHT SECOND ROW SAFETY BELT BUCKLE RIGHT SEEK RIGHT SIDE AIR CURTAIN RIGHT TURN RIL SENS IN RIL SENS LH IN RIR SENS IN RIR SENS RH IN ROL SENS IN ROL SENS LH IN ROOF OPENING PANEL MODULE ROR SENS IN ROR SENS RH IN ROW 2 LEFT BELT FEED ROW 2 LEFT BELT RTN ROW 2 LEFT BUCKLE SW ROW 2 RIGHT BELT FEED ROW 2 RIGHT BELT RTN ROW 2 RIGHT BUCKLE SW RR ACTIVE PRK ASSIST SENS RR AMBIENT NOISE 3 - RR DOOR AJAR RR DR AJAR RR HIGH/OFF RR LOW/OFF RR NOISE CANCEL + RR SEAT NTC RR SPKR RR TURN SIG OUT RT FRT SENS 1 RT FRT SENS 2 SDARS/GPS SIG SDL H SDL L SEATS SYSTEM SEEK LEFT/ SEEK RIGHT/ SEN+ SENDER 1 SENS GND SENS RTN SET 1 SET 2 SET 3 SET- SHADE CLOSE SHADE OPEN SHD RTN SHIFT DN SHIFT INTERLOCK SYSTEM SHIFT UP SHORTING BAR SHORTING BAR SHORTING BAR SIDE MARKER PARK SIG RTN SOLID STATE SOUND SYSTEMS SOUND SYSTEMS SOUND SYSTEMS SPD COMAND STAGE 1 STAGE 2 START STOP START/STOP DISABLE SW START/STOP IND START/STOP) STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STEERING COLUMN FEED STEERING COLUMN MEMORY CIRCUIT STEERING COLUMN RTN STEERING WHEEL CLOCK SPRING STEERING WHEEL) STEREO L+ STEREO R+ STRT/STP DIS SW STRT/STP IND SUPPLEMENTAL RESTRAINTS SYSTEM SW 1 SPKR 1 SW 1 SPKR + SW 2 SPKR + SYNC ALERT - TACM+ TEL FWD TEL MTR FWD TEL MTR RWD TEL RWD TEL SENS TFT SIG RTN THERM FD THERM RTN TILT MTR DOWN TILT MTR UP TILT SENS TPA+ TPMS RECEIVER TR 1 TR 2 TR 3 TR 4 TR GND TR-P TRANSMISSIONS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM TSS GND TSS VPWR TSS/OSS GND TSS/OSS VPWR TSS/OSS/ TR GND ETC RTN TFT TSS/OSS/TR GND TSS/OSS/TR VPWR TURN LP TURN/STOP/TAIL STOP TURN/STOP/TAIL STOP TURN UP INCLINE V BATT VAC GND VAC SENSE P VAC SIG VBATT INPUT VIDEO + VIDEO - VIDEO+ VOLUME- VQM BUS PWR W/ ACTIVE PARKING ASSIST W/ ADAPTIVE CRUISE W/ ADAPTIVE CRUISE CONTROL W/ ADAPTIVE STEERING W/ ADAPTIVE STEERING W/O ADAPTIVE STEERING W/ AMBIENT LIGHTING W/ BLIND SPOT MONITORING W/ DAYTIME SIGNATURE LAMPS W/ HEADLAMP LEVELING W/ HEATED SEATS W/ MEMORY W/ PASSENGER POWER SEAT W/ POWER LIFTGATE W/ REAR HEATED SEATS W/ SPLITTER W/O SPLITTER W/ START/ STOP W/ START/STOP W/ START/STOP W/O START/STOP W/ STOP/ START W/ STOP/START W/ STOP/START W/O STOP/START W/ SYNC 3 W/ TOUCH SCREEN W/ TOUCH SCREEN W/O TOUCH SCREEN W/ TOUCH SCREEN, SONY W/ VISTA ROOF W/ VISTA ROOF W/O VISTA ROOF W/O ADAPTIVE STEERING W/O HEATED SEATS W/O MEMORY W/O POWER LIFTGATE W/O START/STOP W/O START/STOP 6 W/ START/STOP 7 W/O STOP/START W/ STOP/START W/O TOUCH SCREEN WAKE-UP WASHER FLUID RESERVOIR) WAVE TRAPPER WINDOW DOWN WINDOW UP WIPER/WASHER SYSTEM ZERO POSITION ZERO POSITION SIG CONSOLE OPEN/ CLOSE SW
