Tire pressure monitoring circuit for Ford Edge I facelift (2010-2014)
Tire pressure monitoring circuit
ANTENNA
BLK WIRE
BLU/GRY WIRE
BRN WIRE
BRN/RED WIRE
COAX CABLE
COMPUTER DATA LINES SYSTEM
GRY/ORG WIRE
HOT AT ALL TIMES BODY CONTROL MODULE FUSE (BCM) (LEFT KICK PANEL)
HS CAN+
INSTRUMENT PANEL CLUSTER (IPC)
INTERNAL ANTENNA RKE RECEIVER
K LINE
MS CAN +
MS CAN+ TPMS RECEIVER
RED WIRE
REMOTE FUNCTION ACTUATOR (RFA) MODULE (W/ INTELLIGENT ACCESS) (BEHIND GLOVE BOX)
VBATT
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
