Second row seat release circuit for Ford Edge I facelift (2010-2014)
Second row seat release circuit
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (BCM) (LEFT KICK PANEL)
BRN WIRE
FUSE
GRN WIRE
GRN/BRN WIRE
GRY WIRE
GRY/BRN WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES BATTERY FUSE JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
LEFT REAR SEAT RELEASE ACTUATOR
LEFT RELEASE
MICRO -
MKX W/ REAR HEATED SEATS
ORG/ WIRE
REAR POWER SEAT RELEASE SWITCH
REAR SEAT RELEASE RELAY
RED WIRE
RIGHT REAR SEAT RELEASE ACTUATOR
RIGHT RELEASE
SEAT ENABLE (FET)
VIO WIRE
WHT WIRE
