Ford Edge I facelift (2010-2014) Parking assistant circuit

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ISD-R REAR SOUNDER + HS CAN + GND BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BODY CONTROL MODULE (BCM) (LEFT KICK PANEL) BRN/BLU WIRE COMPUTER DATA LINES SYSTEM FUSE 34 GRN/WHT WIRE HOT IN START OR RUN HS CAN - SENSOR GND RIR SENSOR IN RIL SENSOR IN ROL SENSOR IN ROR SENSOR IN INNER LEFT PARKING AID SENSOR (LEFT SIDE OF REAR BUMPER) INNER RIGHT PARKING AID SENSOR (RIGHT SIDE OF REAR BUMPER) OUTER LEFT PARKING AID SENSOR (LEFT END OF REAR BUMPER) OUTER RIGHT PARKING AID SENSOR (RIGHT END OF REAR BUMPER) PARKING AID MODULE (PAM) (BASE "D" PILLAR) PARKING AID SPEAKER REAR SENSOR PWR REAR SOUNDER - SOLID STATE VIO/BRN WIRE WHT WIRE WHT/BLU WIRE WHT/ORG WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE
