Blind spot information system circuit for Ford Edge I facelift (2010-2014)
Blind spot information system circuit
1 2 3 4 5 6 ALERT ISP-R MS CAN+ MS CAN- GND ADDRESS
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU/BRN WIRE
BODY CONTROL MODULE (BCM) (LEFT KICK PANEL)
COMPUTER DATA LINES SYSTEM
DRIVER SIDE EXTERIOR REAR VIEW MIRROR
FUSE 34
GND MS CAN- MS CAN+ ISP-R ALERT
GRY/ORG WIRE
HOT IN RUN OR START
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
NCA WIRE
PASSENGER SIDE EXTERIOR REAR VIEW MIRROR
RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R) (REAR OF VEHICLE)
VIO/BRN WIRE
VIO/ORG WIRE
YEL/GRN WIRE
