Cooling fan circuit, with trailer tow for Ford Edge I facelift (2010-2014)
Cooling fan circuit, with trailer tow
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
CHT
COOLING FAN
COOLING FAN MODULE (LEFT FRONT OF ENGINE COMPT)
CYLINDER HEAD TEMPERATURE (CHT) SENSOR (FRONT OF RIGHT CYLINDER BANK)
ELECTRONICS
FAN CONTROL VARIABLE
FUSE 39
FUSE 40
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT) SIGRTN
PWR
RED WIRE
WHT WIRE
