Passive anti-theft circuit, without intelligent access for Ford Edge I facelift (2010-2014)
Passive anti-theft circuit, without intelligent access
BLK/GRY WIRE
BODY CONTROL MODULE (BCM) (LEFT KICK PANEL)
COMPUTER DATA LINES SYSTEM
EPATS RX
EPATS TX
EXCEPT 2.0L 2.0L
FUSE 18
GROUND
HOT AT ALL TIMES
HS CAN+
MICRO -
PASSIVE ANTI-THEFT TRANSCEIVER (LEFT SIDE OF DASH)
PCM WAKEUP (FET)
POWER
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/BLU WIRE
YEL/ORG WIRE
