Ford Edge I facelift (2010-2014) except sync gen 2 wiring diagram
This page shows the only wiring diagram for the component.except sync gen 2, which is found in the car Ford Edge I facelift (2010-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
except sync gen 2 wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 VBATT
1 33 15 14 37 VBATT SHIELD VIDEO- VIDEO+ GND
ACCESSORY PROTOCOL INTERFACE MODULE (APIM) (CENTER OF DASH)
BLK WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BODY CONTROL MODULE (BCM)
BRN VIO/ WIRE
BRN/VIO WIRE
CHOKE
COMPUTER DATA LINES SYSTEM
ELECTRONICS
EXCEPT SYNC GEN 2
FRONT CONTROL/ DISPLAY INTERFACE MODULE (FCDIM) (CENTER OF DASH)
FUSE 29
FUSE 34 MICRO LIN 03
GRN WIRE
GRN/ WHT WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN START OR RUN
I CAN+ I CAN- VIDEO+
LIN
NCA WIRE
RED WIRE
SYNC GEN 2
VIDEO CAMERA (CENTER OF LIFTGATE)
VIDEO+
VIO BRN/ WIRE
VIO WIRE
VIO/BRN WIRE
VIO/GRY WIRE
WHT GRN/ WIRE
WHT WIRE
WHT/GRN WIRE
Go to component -> Rear camera circuit -> EXCEPT SYNC GEN 2
