Ford Edge I facelift (2010-2014) ctrl mode Wiring diagrams
This page contains all the electrical diagrams for the component. ctrl mode, in which he is found in the car Ford Edge I facelift (2010-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ctrl mode (1 of 2)
ACCESSORY PROTOCOL INTERFACE MODULE (APIM) (IF EQUIPPED)
AUDIO CONTROL MODULE (ACM) (CENTER OF DASH)
BLK/GRY WIRE
BLU/GRY WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM) FUSE (LEFT KICK PANEL)
BRN/BLU WIRE
BRN/YEL WIRE
CLOCKSPRING (STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
CTRL MODE
DOWN
ENABLE
FRONT CONTROL INTERFACE MODULE (FCIM) (CENTER OF DASH)
FUSE
GRY/RED WIRE
HARNESS)
HAZ SW
HOT AT ALL TIMES
HS CAN+
I CAN -
INSTRUMENT CLUSTER
LEFT
LF SPKR
LOGIC GND
MEDIA (W/O SYNC) PPT (W/ SYNC)
MUTE (W/O SYNC) PHONE (W/ SYNC)
NCA WIRE
RF SPKR
RH SW GND
RIGHT
RIGHT STEERING WHEEL SWITCH
SEEK
STEERING COLUMN CONTROL MODULE (SCCM) (STEERING COLUMN)
SYNC ALERT -
VBATT
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/RED WIRE
VOL (-)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/VIO WIRE
Go to component -> Navigation circuit, with sony (2 of 2) -> CTRL MODE
