Power seats circuit, 6-way driver seat for Ford Edge I (2006-2010)

Power seats circuit, 6-way driver seat

Get access

AFT FWD BATTERY BLK WIRE BLU WIRE BRN WIRE DOWN DOWN UP DRIVER SEAT FRONT HEIGHT MOTOR (UNDER DRIVER'S SEAT) DRIVER SEAT HORIZONTAL MOTOR (UNDER DRIVER'S SEAT) DRIVER SEAT REAR HEIGHT MOTOR (UNDER DRIVER'S SEAT) FRONT HEIGHT FUSE JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) GRN WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE HORIZONTAL HOT AT ALL TIMES LEFT POWER SEAT SWITCH REAR HEIGHT RED WIRE VIO WIRE WHT WIRE YEL WIRE
