Car Wiring Diagrams for Electrochromic mirror circuit, with microphone for Ford Edge I (2006-2010)

AUDIO CONTROL MODULE (ACM) AUTO- DIMMING INTERIOR MIRROR UNIT BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE COMPASS FUSE GRN WIRE GRN/BRN WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT W/ ACCESSORY DELAY RELAY ENERGIZED INSTRUMENT CLUSTER (IC) LEFT SIDE EXTERIOR REAR VIEW MIRROR (W/ MEMORY) MIC - NCA WIRE POWER DISTRIBUTION SYSTEM REV LP CTRL REVERSING LAMPS RELAY SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) W/ VOICE ACTIVATED NAVIGATION W/O SYNC YEL/GRN WIRE
