Power door locks circuit for Ford Edge I (2006-2010)

ACCESSORY DELAY RELAY ALL LOCK, UNLOCK RELAY BLK WIRE BLK/GRN WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE DRIVER DOOR UNLOCK RELAY DRIVER SIDE DOOR LOCK SWITCH EDGE FUSE 17 FUSE 41 TO LIFTGATE RELEASE FET (DIAGRAM 2 OF 2) GRN WIRE GRY WIRE GRY/BRN WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT REAR DOOR LOCK ACTUATOR (REAR OF LEFT REAR DOOR) LOCK LR DOOR AJAR MKX NEAR BREAKOUT TO LEFT FRONT TWEETER) INTERIOR LIGHTS SYSTEM PASS TRIM DOOR LOCK AJAR PASSENGER SIDE DOOR LOCK SWITCH POWER DISTRIBUTION SYSTEM RIGHT FRONT DOOR LOCK ACTUATOR (REAR OF FRONT PASSENGER'S DOOR) RIGHT REAR DOOR LOCK ACTUATOR (REAR OF RIGHT REAR DOOR) RR DOOR AJAR SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) MICRO TRIM UNLOCK UNLOCK VIO WIRE VIO/GRY WIRE WHT WIRE YEL WIRE

ANTI-THEFT ANTI-THEFT HOOD SWITCH (RIGHT FRONT OF ENGINE COMPT) BLK WIRE BLK/GRY WIRE BLU WIRE BLU/GRN WIRE BLU/ORG WIRE BRN WIRE BRN/YEL WIRE DOOR RESET SW FROM FUSE 17 (DIAGRAM 1 OF 2) FUSE 5 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE HOT AT ALL TIMES INTERNAL RKE/ TPMS ANTENNA RKE RECEIVER KEYLESS ENTRY KEYPAD KEYPAD ILLUM (FET) LEFT FRONT DOOR LOCK ACTUATOR (REAR OF DRIVER'S DOOR) LF DOOR AJAR LICENSE LAMPS/ LIFTGATE RELEASE SWITCH LIFTGATE AJAR SWITCH (LOWER RIGHT SIDE OF LIFTGATE) LIFTGATE REL (FET) MICRO - MKX ORG/ WIRE RESET+ SET- SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) VIO WIRE W/ MEMORY WHT WIRE YEL WIRE
