Parking assistant circuit for Ford Edge I (2006-2010)

Parking assistant circuit

Edge Ford I (2006-2010): Parking assistant circuit

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PWR RUN REAR SOUNDER + MS CAN + GND BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM FUSE 35 GRN/WHT WIRE GRY/ORG WIRE HOT IN START OR RUN INNER LEFT PARKING AID SENSOR (BEHIND LEFT SIDE OF REAR BUMPER) INNER RIGHT PARKING AID SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER) MS CAN - REAR SENSOR GND RIR SENSOR IN RIL SENSOR IN ROL SENSOR IN ROR SENSOR IN OUTER LEFT PARKING AID SENSOR (BEHIND LEFT END OF REAR BUMPER) OUTER RIGHT PARKING AID SENSOR (BEHIND RIGHT END OF REAR BUMPER) PARKING AID MODULE (BEHIND LEFT REAR QUARTERPANEL) PARKING AID SPEAKER REAR SENSOR PWR REAR SOUNDER - SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) VIO/ORG WIRE WHT/ORG WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/ORG WIRE
