Car Wiring Diagrams for Cruise control circuit for Ford Edge I (2006-2010)

10 20 8 9 OSS TSS/OSS VPWR TR GND TSS/OSS GND 45 41 14 TSS/OSS/TR GND TSS/OSS VPWR OSS 54 47 46 2 3 65 KAPWR BPS STOPLAMP HS CAN + HS CAN - ACCELERATOR PEDAL POSITION (APP) SENSOR (TOP OF ACCELERATOR PEDAL) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/VIO WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRAKE PEDAL POSITION (BPP) SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) BRN WIRE BRN/BLU WIRE BRN/GRN WIRE CLOCK SPRING (ON STEERING WHEEL COLUMN) COMPUTER DATA LINES SYSTEM COOLING FAN MODULE ELECTRONIC THROTTLE CONTROL (ETC) MOTOR (ON THROTTLE BODY) FUSE 21 FUSE 32 FUSE 71 GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ PCM POWER RELAY ENERGIZED ILLUMINATION JUNCTION, NEAR BREAKOUT TO LEFT STEERING WHEEL SWITCH OFF POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE) RESUME SCCS SCCSRTN CASE GND SET- TPREF TACM+ TACM- TPRTN VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE
