Ford Edge I (2006-2010) right reversing lamp Wiring diagrams

AUTO DIMMING INTERIOR MIRROR BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLU WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE EDGE MKX FUSE 44 GRN WIRE GRN/BRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REVERSING LAMP POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE) REV LMP CTL 17 18 19 32 REVERSING LAMPS RELAY RIGHT REVERSING LAMP VIO WIRE VIO/WHT WIRE W/ MICROPHONE W/O MICROPHONE, W/ ILLUM VISOR W/O MICROPHONE, ILLUM VISOR WHT WIRE YEL WIRE

ACCESSORY PROTOCOL INTERFACE MODULE (APIM) AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE) BLK WIRE BLK/GRY WIRE CARGO AREA POWER POINT EDGE GRN WIRE GRY WIRE HIGH MOUNTED STOP LAMP ILLUMINATED LIFTGATE APPLIQUE LEFT LICENSE PLATE LAMP LEFT REAR MARKER LAMP LEFT REAR PARK/ STOP/ TURN LAMP LEFT REVERSING LAMP LICENSE LAMPS LIFT- GATE AJAR SWITCH LIFTGATE CINCHING MOTOR LIFTGATE DRIVE UNIT LIFTGATE REAR CONTROL SWITCH LIFTGATE RELEASE SWITCH LIFTGATE/ TRUNK MODULE (LTM) MKX REAR WINDOW DEFROST GRID REAR WINDOW WIPER MOTOR RIGHT LEFT LICENSE REAR PLATE MARKER LAMP LAMP RIGHT REAR MARKER LAMP RIGHT REAR PARK/ STOP/ TURN LAMP RIGHT REAR SEAT HEATER ELEMENT RIGHT REAR SEAT RELEASE ACTUATOR RIGHT REVERSING LAMP SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDARS) MODULE STABILITY CONTROL SENSOR CLUSTER SUBWOOFER TRAILER TOW CONNECTOR W/ AUDIOPHILE AUDIO W/ POWER LIFTGATE W/ TXH AUDIO W/O POWER LIFTGATE W/O THX AUDIO WHT WIRE YEL WIRE
