Ford Edge I (2006-2010) right down left Wiring diagram

This page shows the only wiring diagram for the component.right down left, which is found in the car Ford Edge I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram right down left (1 of 1)

Wiring diagram right down left for Ford Edge I (2006-2010)

Get access

BLK WIRE BLU/GRN WIRE BRN/BLU WIRE BRN/WHT WIRE DOWN UP EXTERIOR REAR VIEW MIRROR SWITCH FUSE 12 GRN/RED WIRE GRY WIRE HOT AT ALL TIMES LEFT RIGHT LEFT SIDE EXTERIOR REAR VIEW MIRROR LEFT/ RIGHT UP/ DOWN MIRROR SELECT RIGHT DOWN LEFT RIGHT LEFT RIGHT SIDE EXTERIOR REAR VIEW MIRROR SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) YEL/VIO WIRE

Go to component: -> Power mirrors circuit -> RIGHT DOWN LEFT
