Ford Edge I (2006-2010) rear power seat release switch Wiring diagram

This page shows the only wiring diagram for the component.rear power seat release switch, which is found in the car Ford Edge I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram rear power seat release switch (1 of 1)

Wiring diagram rear power seat release switch for Ford Edge I (2006-2010)

Get access

BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK/GRN WIRE BLK/WHT WIRE BLU WIRE FUSE FUSE 27 GRN/BRN WIRE GRY/BRN WIRE HOT AT ALL TIMES JOINT CONNECTOR 7 (LEFT REAR OF ENGINE COMPT) LEFT LEFT REAR SEAT RELEASE ACTUATOR (UNDER LEFT REAR SEAT) MICRO - REAR POWER SEAT RELEASE SWITCH REAR SEAT RELEASE RELAY RIGHT RIGHT REAR SEAT RELEASE ACTUATOR (UNDER RIGHT REAR SEAT) SEAT ENABLE (FET) SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) WHT/BRN WIRE

Go to component: -> Second row seat release circuit -> REAR POWER SEAT RELEASE SWITCH
