Ford Edge I (2006-2010) outer right parking aid sensor (behind right end of rear bumper) wiring diagram
This page shows the only wiring diagram for the component.outer right parking aid sensor (behind right end of rear bumper), which is found in the car Ford Edge I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
outer right parking aid sensor (behind right end of rear bumper) wiring diagram (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PWR RUN REAR SOUNDER + MS CAN + GND
BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 35
GRN/WHT WIRE
GRY/ORG WIRE
HOT IN START OR RUN
INNER LEFT PARKING AID SENSOR (BEHIND LEFT SIDE OF REAR BUMPER)
INNER RIGHT PARKING AID SENSOR (BEHIND RIGHT SIDE OF REAR BUMPER)
MS CAN - REAR SENSOR GND RIR SENSOR IN RIL SENSOR IN ROL SENSOR IN ROR SENSOR IN
OUTER LEFT PARKING AID SENSOR (BEHIND LEFT END OF REAR BUMPER)
OUTER RIGHT PARKING AID SENSOR (BEHIND RIGHT END OF REAR BUMPER)
PARKING AID MODULE (BEHIND LEFT REAR QUARTERPANEL)
PARKING AID SPEAKER
REAR SENSOR PWR
REAR SOUNDER -
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
VIO/ORG WIRE
WHT/ORG WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/ORG WIRE
