Ford Edge I (2006-2010) multi- function switch (top of steering column) Wiring diagrams
This page contains all the electrical diagrams for the component. multi- function switch (top of steering column), in which he is found in the car Ford Edge I (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
multi- function switch (top of steering column) wiring diagram (1 of 2)
47 8 46 BPS PCM RLY BOO
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BRAKE PEDAL POSITION (BPP) SWITCH (ON BRAKE PEDAL SUPPORT BRACKET)
BRN/WHT WIRE
BRN/YEL WIRE
FUSE
FUSE 32
GRN/VIO WIRE
GRY/BRN WIRE
GRY/YEL WIRE
HAZARD SWITCH
HAZARD/ PAD/ TRACTION SWITCH
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
LEFT TURN
LICENSE LAMPS
MULTI- FUNCTION SWITCH (TOP OF STEERING COLUMN)
PARK
PARK/STOP/ TURN LAMP (LEFT REAR)
PARK/STOP/ TURN LAMP (RIGHT REAR)
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE)
REAR MARKER LAMP
REAR MARKER LAMP (LEFT)
RIGHT
RIGHT TURN
STOP TURN
STOP/ TURN PARK
TRAILER TOW LEFT STOP/ TURN RELAY
TRAILER TOW PARK RELAY
TRAILER TOW RIGHT STOP/ TURN RELAY
VIO/GRY WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT/RED WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> MULTI- FUNCTION SWITCH (TOP OF STEERING COLUMN)
multi- function switch (top of steering column) wiring diagram (2 of 2)
1 8 3 LOW PARK
3 1 AIR CONDITIONING SYSTEM
9 6 AUTO FOG
AIR CONDITIONING SYSTEM
AUTO- FOG LAMP LAMP LAMP LAMP LAMP ON OFF ON PASS BEAM ON CAN+
AUTOLAMPS SNSR IN
AUTOMATIC A/C
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER WIPER/ DATA LINES WASHER SYSTEM SYSTEM
FLASH TO HIGH MS MS
FOG IND
FOG LAMP RELAY
FTP
FUSE 21
FUSE 23
FUSE 7
FUSE 8
GRN/BRN WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HEAD- PARK HEAD-
HEADLAMP SWITCH
HI BEAM
HIGH BEAM RELAY
HOT AT ALL TIMES
ILL
INSTRUMENT CLUSTER (IC)
JOINT CONNECTOR 7 (LEFT REAR OF ENGINE COMPT)
LEFT FRONT FOG LAMP
LEFT FRONT HIGH BEAM LAMP
LEFT FRONT LOW BEAM LAMP
LEFT LOW BEAM (FET)
LIGHT SENSOR (UNDER TOP CENTER OF DASH)
MANUAL A/C
MICRO -
MS CAN +
MULTI- FUNCTION SWITCH (TOP OF STEERING COLUMN)
OFF
RIGHT FRONT FOG LAMP
RIGHT FRONT HIGH BEAM LAMP
RIGHT FRONT LOW BEAM LAMP
RIGHT LOW BEAM (FET)
SMART JUNCTION BOX (SJB)
SUNLOAD SENSOR
VIO/GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT WIRE
WHT/ORG WIRE
WHT/VIO WIRE
WIPER CAN- STATUS
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Headlamps circuit -> MULTI- FUNCTION SWITCH (TOP OF STEERING COLUMN)
