Ford Edge I (2006-2010) multi-function switch 1. off 2. interval 1 3. interval 2 4. rear wash Wiring diagram

This page shows the only wiring diagram for the component.multi-function switch 1. off 2. interval 1 3. interval 2 4. rear wash, which is found in the car Ford Edge I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram multi-function switch 1. off 2. interval 1 3. interval 2 4. rear wash (1 of 1)

Wiring diagram multi-function switch 1. off 2. interval 1 3. interval 2 4. rear wash for Ford Edge I (2006-2010)

Get access

BLK WIRE BLU WIRE ELECTRONICS FRONT WASHER RELAY FUSE 19 FUSE 43 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN RUN OR ACC JOINT CONNECTOR 7 (LEFT REAR OF ENGINE COMPT) MULTI-FUNCTION SWITCH 1. OFF 2. INTERVAL 1 3. INTERVAL 2 4. REAR WASH REAR WASHER RELAY REAR WINDOW WIPER MOTOR (IN LIFTGATE) REAR WIPER RED WIRE SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH) SMART WIPER MODULE (LEFT REAR OF ENGINE COMPT) UP WIPER RELAY VIO WIRE WHT WIRE WINDSHIELD WASHER PUMP MOTOR (ON WASHER FLUID RESERVOIR) YEL WIRE

Go to component: -> Rear washer/wiper circuit -> MULTI-FUNCTION SWITCH 1. OFF 2. INTERVAL 1 3. INTERVAL 2 4. REAR WASH
