Ford Edge I (2006-2010) low washer Wiring diagram
This page shows the only wiring diagram for the component.low washer, which is found in the car Ford Edge I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low washer (1 of 1)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BRN WIRE
ELECTRONICS
FRONT WASHER RELAY
FRONT WASHER SWITCH
FRONT WIPER
FUSE 19
FUSE 29
FUSE 43
FUSE 45
FUSE 58
GRN WIRE
GRY WIRE
HALL SENSOR
HIGH/LOW SPEED RELAY
HOT AT ALL TIMES
HOT IN RUN OR ACC
HOT IN RUN OR START
INSTRUMENT CLUSTER
JOINT CONNECTOR 7 (LEFT REAR OF ENGINE COMPT)
LOW WASHER
MULTI- FUNCTION SWITCH
OF ENGINE)
ORG/ WIRE
PARK
POWERTRAIN CONTROL MODULE (RIGHT FRONT
REAR WASHER RELAY
REAR WINDOW WIPER MOTOR (IN LIFTGATE)
RED WIRE
RUN WIRE
RUN/PARK RELAY
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
SMART WIPER MODULE (LEFT REAR OF ENGINE COMPT)
UP WIPER RELAY
VIO WIRE
VIO/ORG WIRE
VPWR
VSS OUT
W/ ADAPTIVE HEADLIGHTS
WHT WIRE
WHT/VIO WIRE
WINDSHIELD WASHER PUMP MOTOR (ON WASHER FLUID RESERVOIR)
WIPER STATUS
YEL WIRE
Go to component: -> Front wiper/washer circuit -> LOW WASHER
