Ford Edge I (2006-2010) gps antenna Wiring diagrams
This page contains all the electrical diagrams for the component. gps antenna, in which he is found in the car Ford Edge I (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
gps antenna wiring diagram (1 of 3)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 VBATT+ DEL/ACC
ACCESSORY DELAY RELAY
ANT PWR
ANTENNA MODULE (BEHIND RIGHT KICK PANEL)
ANTENNA SHIELD
AUDIO CONTROL MODULE (ACM)
AUDIO INPUT JACK
BLK/BLU WIRE
BLU WIRE
BLU/GRN WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COAXIAL CABLE
COMPUTER DATA LINES SYSTEM
EDGE
FUSE 28
FUSE 39
FUSE 41
GPS ANTENNA
GRN/ORG WIRE
GRY WIRE
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT IN
LEFT FRONT SPEAKER
LEFT FRONT TWEETER
LEFT REAR SPEAKER
LF SPKR+ LR SPKR+ RR SPKR+ RF SPKR+ RF SPKR- PWR GND
LF SPKR- LR SPKR- RR SPKR-
MICRO -
MKX
MS CAN - MS CAN +
NCA WIRE
RED WIRE
RIGHT FRONT SPEAKER
RIGHT FRONT TWEETER
RIGHT REAR SPEAKER
SHIELD
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
TWISTED PAIR WIRES
VIO WIRE
VIO/ORG WIRE
W/ NAVIGATION
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/GRN WIRE
YEL/ORG WIRE
Go to component -> Base radio circuit -> GPS ANTENNA
gps antenna wiring diagram (2 of 3)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 VBATT+ DEL/ACC
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 STEREO L + STEREO L -
1 2 3 4 5 6 7 8 SUB+ SUB- SUB SHIELD SUB ENABLE
ACCESSORY DELAY RELAY
ANT PWR
ANTENNA MODULE (BEHIND RIGHT KICK PANEL)
ANTENNA SHIELD
AUDIO CONTROL MODULE (ACM)
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COAXIAL CABLE
COMPUTER DATA LINES SYSTEM
FUSE 28
FUSE 3
FUSE 38
FUSE 39
FUSE 41
GPS ANTENNA
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT IN
LEFT REAR SPEAKER (W/O DVD REAR ENTERTAINMENT CENTER)
LF SPKR+ LR SPKR+ RR SPKR+ RF SPKR+ RF SPKR- PWR GND
LF SPKR- LR SPKR- RR SPKR-
MICRO -
MONO + MONO -
MS CAN - MS CAN +
NCA WIRE
PWR
RED WIRE
RIGHT REAR SPEAKER (W/O DVD REAR ENTERTAINMENT CENTER)
SMART JUNCTION BOX (SJB) (LEFT SIDE OF DASH)
STEREO R + STEREO R - MIC + MIC -
SUB +
SUB ENABLE
SUBWOOFER
TWISTED PAIR WIRES
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
W/ NAVIGATION
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/GRN WIRE
Go to component -> Premium radio circuit, with sync (1 of 3) -> GPS ANTENNA
gps antenna wiring diagram (3 of 3)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 VBATT+ DEL/ACC
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 STERIO 1 L+ STERIO 1 L- SHIELD
1 2 3 4 5 6 7 8 NAV MONO+ NAV MONO- SHIELD ENABLE
ANTENNA
ANTENNA PWR
ANTENNA SHIELD
AUDIO CONTROL MODULE (ACM)
AUDIO INPUT JACK
AUTO- DIMMING INTERIOR MIRROR UNIT
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/ORG WIRE
BLU/WHT WIRE
BRN/WHT WIRE
COAXIAL CABLE
COMPUTER DATA LINES SYSTEM
GPS ANTENNA
GRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/VIO WIRE
GRY/YEL WIRE
LF SPEAKER (+)
MIC -
MS CAN +
MS CAN - MS CAN +
NCA WIRE
RF SPEAKER+ RF SPEAKER- GND
SATELLITE DIGITAL AUDIO RECEIVER SYSTEM (SDRS) MODULE
SHIELD
STERIO 1 L-
STERIO 1 R+ STERIO 1 R- MIC + MIC -
STERIO 1 R-
SWC 1 SWC 1 RTN
VBATT
VIO/BRN WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/RED WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Thx audio radio circuit (3 of 3) -> GPS ANTENNA
