Ford Edge I (2006-2010) cooling fans Wiring diagram

This page shows the only wiring diagram for the component.cooling fans, which is found in the car Ford Edge I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram cooling fans (1 of 1)

Wiring diagram cooling fans for Ford Edge I (2006-2010)

Get access

BLK WIRE BLU WIRE CHT COOLING FAN MODULE (LEFT FRONT OF ENGINE COMPT) ELECTRONICS COOLING FANS CYLINDER HEAD TEMPERATURE SENSOR (FRONT OF RIGHT CYLINDER BANK) E-SIGRTN FAN CONTROL VARIABLE GRN WIRE GRY WIRE HOT AT ALL TIMES BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENG COMPT) FUSE 5 POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE) FAN CONTROL VARIABLE PWR RED WIRE VIO WIRE WHT WIRE

Go to component: -> Cooling fan circuit, without trailer tow -> COOLING FANS
