Ford Edge I (2006-2010) ambient air temperature sensor Wiring diagram

This page shows the only wiring diagram for the component.ambient air temperature sensor, which is found in the car Ford Edge I (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram ambient air temperature sensor (1 of 1)

Wiring diagram ambient air temperature sensor for Ford Edge I (2006-2010)

Get access

AMBIENT AIR TEMPERATURE SENSOR BLK WIRE BLOWER MOTOR RELAY BLU WIRE BRN WIRE EVAPORATOR DISCHARGE AIR TEMPERATURE SENSOR (LEFT SIDE OF HVAC UNIT) GRN WIRE GRN/BLU WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) FUSE IN-VEHICLE TEMPERATURE SENSOR (BEHIND LEFT SIDE OF DASH) LT GRN/BLK WIRE RED WIRE VIO WIRE VIO/GRN WIRE WHT WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE

Go to component: -> Automatic a/c circuit (2 of 3) -> AMBIENT AIR TEMPERATURE SENSOR
