Ford Edge I (2006-2010) 37 64 58 48 acpt c-ref s-sigrtn fan ctrl Wiring diagrams

This page contains all the electrical diagrams for the component. 37 64 58 48 acpt c-ref s-sigrtn fan ctrl, in which he is found in the car Ford Edge I (2006-2010). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram 37 64 58 48 acpt c-ref s-sigrtn fan ctrl (1 of 2)

Wiring diagram 37 64 58 48 acpt c-ref s-sigrtn fan ctrl for Ford Edge I (2006-2010)

Get access

18 8 3 2 ACCR PCM RLY HS CAN - HS CAN + 37 64 58 48 ACPT C-REF S-SIGRTN FAN CTRL 41 58 CHT S-SIGRTN A/C CLUTCH FIELD COIL (ON A/C COMPRESSOR) A/C CLUTCH RELAY A/C COMPRESSOR CLUTCH DIODE A/C PRESSURE TRANSDUCER SENSOR (RIGHT FRONT OF ENGINE COMPT) BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COOLING FAN MODULE (LEFT FRONT OF ENGINE COMPT) CYLINDER HEAD TEMPERATURE SENSOR (FRONT OF RIGHT CYLINDER BANK) ELECTRONICS FAN CNTRL PWR GND FUSE 35 FUSE 5 FUSE 6 GRN WIRE GRN/WHT WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE HOT AT ALL TIMES JOINT CONNECTOR 7 (LEFT REAR OF ENGINE COMPT) ORG/ WIRE PCM POWER RELAY POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE) RED WIRE VIO WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE W/O TRAILER TOW W/ TRAILER TOW WHT WIRE WHT/BLU WIRE WHT/BRN WIRE YEL WIRE YEL/GRN WIRE YEL/VIO WIRE

Go to component: -> Automatic a/c circuit (3 of 3) -> 37 64 58 48 ACPT C-REF S-SIGRTN FAN CTRL

Wiring diagram 37 64 58 48 acpt c-ref s-sigrtn fan ctrl (2 of 2)

Wiring diagram 37 64 58 48 acpt c-ref s-sigrtn fan ctrl for Ford Edge I (2006-2010)

Get access

18 8 3 2 ACCR PCM RLY HS CAN - HS CAN + 37 64 58 48 ACPT C-REF S-SIGRTN FAN CTRL 4 1 2 FAN CNTRL PWR GND 41 58 CHT S-SIGRTN A/C CLUTCH FIELD COIL (ON A/C COMPRESSOR) A/C CLUTCH RELAY A/C COMPRESSOR CLUTCH DIODE A/C PRESSURE TRANSDUCER SENSOR (RIGHT FRONT OF ENGINE COMPT) BATTERY JUNCTION BOX (BJB) BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLOWER MOTOR RELAY BLU WIRE BLU/GRY WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COOLING FAN MODULE (LEFT FRONT OF ENGINE COMPT) CYLINDER HEAD TEMPERATURE SENSOR (FRONT OF RIGHT CYLINDER BANK) ELECTRONICS ENGINE CONTROLS SYSTEM FUSE 35 FUSE 5 FUSE 6 FUSE GRN WIRE GRN/WHT WIRE GROUND DISTRIBUTION SYSTEM GRY WIRE HOT AT ALL TIMES JOINT CONNECTOR 7 (LEFT REAR OF ENGINE COMPT) ORG/ WIRE PCM POWER RELAY POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE) RED WIRE VIO WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE W/O TRAILER TOW W/ TRAILER TOW WHT WIRE WHT/BLU WIRE WHT/BRN WIRE YEL WIRE YEL/GRN WIRE YEL/VIO WIRE

Go to component: -> Manual a/c circuit (2 of 2) -> 37 64 58 48 ACPT C-REF S-SIGRTN FAN CTRL
