Ford Edge I (2006-2010) 16 21 25 26 27 28 59 65 66 67 68 69 70 overdrive cancel Wiring diagram

16 21 25 26 27 28 59 65 66 67 68 69 70 OVERDRIVE CANCEL 2 3 55 7 8 51 52 53 46 47 HS CAN+ HS CAN- FEPS IGNITION PCM RLY CTRL 58 41 34 51 59 60 61 66 E-SIGRTN CHT TACM+ TACM- TPRTN ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL) BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT) BLK/VIO WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BOO BPS BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT BRACKET) BRN WIRE BRN/GRN WIRE BRN/WHT WIRE CASE GND PWR GND 1 PWR GND 2 PWR GND 3 PWR GND 4 COMPUTER DATA LINES SYSTEM CYLINDER HEAD TEMPERATURE SENSOR (FRONT OF RIGHT CYLINDER BANK) ELECTRONIC THROTTLE CONTROL (ETC) (ON THROTTLE BODY) FUSE 30 FUSE 32 FUSE 71 FUSE 49 GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN START OR RUN PCM POWER RELAY POWERTRAIN CONTROL MODULE (PCM) (RIGHT FRONT OF ENGINE) TPREF VIO/GRN WIRE VIO/GRY WIRE VIO/ORG WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE
