Warning systems circuit for Ford EcoSport II facelift (2017-2024)

AUTOLAMP AUTOLAMP ON BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/GRY WIRE BODY CONTROL MODULE (BCM) BRAKE FLUID LEVEL SWITCH BRK LEVEL SW BUCKLE SIG COMPUTER DATA LINES SYSTEM DRIVER SIDE FRONT SAFETY BELT BUCKLE SWITCH DRV BUCKLE SIG FUSE 4 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/VIO WIRE H/L ON HEAD/PARK HEADLAMP SWITCH HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) MODULE KEY IN KEY-IN IGNITION SWITCH LAMPS OFF LEFT FRONT DOOR LATCH LEFT REAR DOOR LATCH LF DOOR AJAR LOW BEAM REQ LR DOOR AJAR MICRO - MULTI- FUNCTION SWITCH NCA WIRE OFF PARK PARK BRAKE SW PARK LAMPS ON PARKING BRAKE SWITCH RED WIRE RESTRAINTS CONTROL MODULE (RCM) RF DOOR AJAR RIGHT FRONT DOOR LATCH RIGHT REAR DOOR LATCH RR DOOR AJAR RTN STEERING COLUMN CONTROL MODULE (SCCM) SUPPLEMENTAL RESTRAINTS SYSTEM VIO/GRN WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE
