Blind spot information system circuit for Ford EcoSport II facelift (2017-2024)
Blind spot information system circuit
BATTERY JUNCTION BOX (BJB)
BLIS IND
BLK/VIO WIRE
BLK/YEL WIRE
BLU/BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 58
GRY/ORG WIRE
HOT W/ RUN/START RELAY ENERGIZED
LEFT EXTERIOR MIRROR
LEFT SIDE OBSTACLE DETECTION (SOD-L) CONTROL MODULE
MS CAN +
RIGHT EXTERIOR MIRROR
RIGHT SIDE OBSTACLE DETECTION (SOD-R) CONTROL MODULE
VIO/ORG WIRE
VPWR
WHT/ORG WIRE
YEL/GRN WIRE
