Computer data lines circuit for Ford EcoSport II facelift (2017-2024)

AUDIO CONTROL MODULE (ACM) BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (BCM) CAN (+) CHAS GND DATA LINK CONNECTOR (DLC) EATC EMTC FUSE 22 FUSE 24 GATEWAY MODULE GRN/BLU WIRE GRN/ORG WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/RED WIRE HOT AT ALL TIMES HVAC CONTROL MODULE LEFT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-L) MICRO - MS CAN + MS CAN + VBATT ORG/ WIRE RIGHT SIDE OBSTACLE DETECTION CONTROL MODULE (SOD-R) SIG GND TRAILER TOW MODULE VBATT VIO/ORG WIRE VIO/RED WIRE W/O BLIS WHT WIRE WHT/BLU WIRE WHT/GRN WIRE

2.0L ANTI-LOCK BRAKE SYSTEM (ABS) MODULE AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE) BLK/WHT WIRE BLU WIRE COMPACT DISC PLAYER EXTENDED POWER MODULE GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRY/BLU WIRE INSTRUMENT PANEL CLUSTER (IPC) MODULE OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) ORG/ WIRE PARKING AID MODULE (PAM) POWER STEERING CONTROL MODULE (PSCM) POWERTRAIN CONTROL MODULE (PCM) RESTRAINTS CONTROL MODULE (RCM) STEERING COLUMN CONTROL MODULE (SCCM) SYNC MODULE (APIM) TELEMATICS CONTROL UNIT (TCU) W/ TOUCH SCREEN W/O TOUCH SCREEN WHT WIRE WHT/BLU WIRE WHT/GRN WIRE
