Ford Econoline E350 (1997-1998) Wiper/washer circuit

1 2 3 4 5 6 7 8 9 10 11 12 13 14 WIPER MODE POWER GROUND WSHR PUMP GROUND BLK WIRE BLK/LT BLU WIRE BLK/PNK WIRE BLK/WHT WIRE BRN/WHT WIRE COMMON WIPER LOW INTRVL CTL COMMON POWER DK BLU/ORG WIRE DK BLU/WHT WIRE DK GRN WIRE FUSE 9 HOT IN ACC OR RUN I/P FUSE PANEL (BEHIND LEFT SIDE OF DASH) INT MAX LO INT MIN OHMS MULTI- FUNCTION SWITCH OFF OFF INT MAX OHMS INT MIN OHMS ORG/ WIRE PARK PARK SW WIPER HIGH RUN WIRE WASH WASHER PUMP (ON RIGHT FENDER APRON) WHT WIRE WINDSHIELD WIPER MOTOR (LEFT REAR OF ENGINE COMPT) WIPER CONTROL MODULE (BEHIND CENTER OF DASH) YEL/RED WIRE
